1700℃ Crucible Furnace

1100 Degree Vertical Tube Furnace With Vacuum Pump Optional And Quartz Tube Dia 50*1000mm SPECIFICATIONS The TOB-VTL1100vertical tube furnaceadopts Electric resistance wire as heating element with fast temperature rising. (up to 1000degrees within 20mins). 40 segments programmable temperature controllers are installed with 6 groups of PID adjustment. Thislaboratory tube furnaceis the ideal laboratory equipment for universities, research institutes, industrial and mining enterprises to do High temperature atmosphere sintering, Atmosphere reduction, CVD experimental, vacuum annealing such as for preparing nano materials and film. Model Tube Size Power Voltage Heating Zone  Length Max Heating  Temperature TOB-VTL1100-I Φ50*1000mm 2.5kw AC110V/220V 450mm 1100℃ TOB-VTL1100-II Φ70*1000mm 4kw TOB-VTL1100-II Φ100*1000mm 7kw Heating element Electric resistance wire Temperature controller 40 program temperature control system, With over temperature, broken accidentally protection function, 6 groups of PID adjustment Control precision of + / - 1 ℃ Furnace chamber  Polycrystal alumina fiber Tube material Gas refining quartz tube (or corundum tube) Vacuum Flange &  Fitting Ports Stainless steel flange with Gas nozzle, valve, pressure gauge Pressure measure  system Pressure gauge (Resistance vacuum gauge can be chosen according requirements) Air intake control Flow meter (Protons flow controller can be chosen according requirements ) Vacuum system Vacuum pump can be chosen Warranty One year limited warranty with lifetime support  Email : tob.amy@tobmachine.com  Skype : amywangbest86  Whatsapp/Phone number : +86 181 2071 5609

The furnace chamber is made of imported alumina fiber material with a unique design, which is durable, has good thermal insulation performance, and will not collapse. The heating element adopts a silicon-molybdenum rod, greatly improving its service life.

5mm Width Aluminum Tab for polymer lithium ion battery

This TOB-W400-2.4 battery separator coating machine is used for precision coating of lithium-ion battery separators.

 The device is integrated most customers demand and production, a complete, mature, widespread use and other  characteristics, can be directly used for university research or mass production.

300mm Width Battery Coating Machine

The pouch cell case forming machine is mainly completes the functions of manual feeding of aluminum laminated film roll, automatic correction, dust removal by brush, static removal, preheating before punching, punching, rolling cutting on both sides, top cutting, separate collection of waste and finished products, etc.

Automatic Die Cutting / Punching Machine For Anode and Cathode Electrode for Stacking Pouch Cell SPECIFICATIONS This machine is used for make the roll electrode into cell shape electrode automatically. 1 Roll electrode feeding automatically, controlled by Photoelectric switch 2 Adopt laser module to get high efficiency and accuracy Model TOB-04-350-DC Source voltage  AC 220V, 50HZ Power  4.2KW Air compression 0.6-07MPa Suitable battery size ≤350*200mm Max electrode width 360mm Cutter die height 23.8mm Accuracy of struggle 0.1mm Capacity 40-60times/min Dimension 2800*1400*900mm Weight 2500kg Finished electrode of the die cutter machine  Email : tob.amy@tobmachine.com  Skype : amywangbest86  Whatsapp/Phone number : +86 181 2071 5609
