battery machine and materials solution
Products

Hot Products


China Leading Automatic Volumetry Karl Fischer Moisture Analyzer Manufacturer
加载中...

Automatic Volumetry Karl Fischer Moisture Analyzer

TOB-AKF-1 Karl Fischer Moisture Analyzer is an Intelligent moisture tester adopting volumetry method. it is mainly used for scientific research, produce, and education field, with high accuracy and simple operation.
  • Brand:

    TOB NEW ENERGY
  • item no.:

    TOB-AKF-1
  • order(moq):

    1
  • Payment:

    L/C,T/T,Western Union
  • product origin:

    China
  • shipping port:

    XIAMEN
  • Lead Time:

    7
Product Detail

Automatic Volumetry Karl Fischer Moisture Analyzer For Lithium Battery Electrolyte Moisture Analysis


SPECIFICATIONS



1 TOB-AKF-1 Karl Fischer Moisture Analyzer is an Intelligent moisture tester adopting volumetry method. it is mainly used for scientific research, produce, and education field, with high accuracy and simple operation.

2 It can be used for analyzer water in many industries fields such as Medicine, organic solvents, industrial salt, petrochemical industry, chemical fertilizer, agricultural medicine, dyes, food and beverage, surface active agent, cosmetics and so on.

3 This Karl Fischer Moisture Analyzer used for lithium battery industry mainly used for powder materials and electrolyte moisture analyzer


Model

Volumetry Method Karl Fischer Moisture Analyzer TOB-AKF--1

Testing range

0.003-100%

Measuring resolution

1ug

Measuring repeatability

99.7%, (10mg)

Max error

≤1%

Testing time

Average 2-5min

Date storage

100, can be expanded

Buret

20 ml Auto buret

  Titration control precision

0.001ml

Electrode connect

Double platinum electrode

Display mode

LCD, Chinese or English

Data interface

RS-232C, USB, WEB

Working humidity

≤80%

Working temperature

5-40℃

Source voltage

220V / 50HZ, can work with voltage transformer

Power

50W

Dimension(L*W*H)

400*350*280mm

Weight

5.5kg
