Ultrasonic Spot Welding Machine For Anode Electrode

Ultrasonic Spot Welding Machine For Anode Electrode
  • item no.:

    TOB-USW-40KHZ
  • order(moq):

    1set
  • Payment:

    L/C,T/T,Western Union, Paypal
  • product origin:

    China
  • shipping port:

    XIAMEN
  • Lead Time:

    7days
Product Detail

Desk-Top 40KHZ Ultrasonic Metal Welding Machine For Lithium Battery Anode Electrode Nickel Tab Welding With Copper foil


SPECIFICATIONS



TOB-USW-40KHZ Ultrasonic Metal Welding Machine is an ultrasonic metal welder designed for welding li ion battery anode electrode sheets aluminum and Ni tab onto current collectors to prepare Li-Ion pouch cells in R&D laboratories and production line.


Model

Battery Spot Welding Machine For Anode   TOB-USW-40KHZ

Source voltage

110V AC or 220V AC 50/60Hz

Power

800W

Warranty

One Year limited warranty with lifetime support

Type

Ultrasonic metal welding machine

Frequency

40KHZ

Control mode

Pneumatic, with air supply 0.5-0.7Mpa

Welding thickness

0.09mm~0.012mm copper foil+0.1mm nickel tab

Welding size

Standard size is 3*3mm*3, can also customized according request

Working humidity

35%-85%

Working temperature

0℃-40℃

Structure

Adopt the solid crystal type, with functions of automatic frequency

trackingWith overcurrent, overheating, mismatch alarm

Dimension

Controller: 380mm(L) * 340mm(W) *250mm(H)

Welder: 490mm(L) *170mm(W) *240mm(H)

Weight

Welder : 40kg,  Controller : 10kg
