3600W Ultrasonic metal welding machine

3600W Ultrasonic metal welding machine
  • item no.:

    TOB-CX-20DA
  • order(moq):

    1set
  • Payment:

    L/C,T/T,Western Union, Paypal
  • product origin:

    China
  • shipping port:

    XIAMEN
  • Lead Time:

    15days
Product Detail

3600W Ultrasonic metal welding machine


SPECIFICATIONS



Device description:

1.Has a generator with frequency  automatic tracking technology, high quality transducers, highly wear~resistant welding head.

2.Equipment is number position model, pressure, amplitude, welding time etc.parameters use all~digital set and regulation;

3.The use of energy, time, highly welding control mode;

4.Welding energy real time data acquisition, digital display, builtin electronic scale, highly accurate measurement of welding height.

5.All these operations are done on the touch screen.

6. Equipment operation accurate, stable and process control is very simple.


Device parameters and configuration:


Weight

45KG

Case size

480x600x180mm

Rack Dimensions

150x560x350mm

Power

220 V (single-phase)

Air supply requirements

≧ 5 .0kgf / cm²

Operating frequency

20KHZ (automatic tracking, without

 adjustment)

Nominal power

3600W (actual power capacity

 4.5KW);

 maximum pressure: 3000N

Other:   1,5.7 inch touch screen all digital control (including energy, altitude,time of three control

modes; pneumatic NC;100 kinds of parameters are stored call is very convenient.);

   2,Multiple protection functions (over current, frequency protection),boot automatic

detection;   3,Digital stepless amplitude modulation (20~40μm half wave amplitude is continuously

adjustable to adapt to a variety of materials and specifications).


PRODUCT DISPLAY



Ultrasonic metal welding machine



Ultrasonic metal welding machine




PACKAGE AND SHIPPING

1 Standard exported package : Internal anticollision protection, external export wooden box package

2 Shipping by express, by air, by sea according to customer's requirements to suggest the most suitable shipping mode

3 Responsible for the damage during shipping process, change the damage part for free

4 Supply with suitable voltage input and power plug according to customer's country requirements.

5 Supply with CO, ECO, FORM A, FORM E and any other original certificate for import custom clearance and tax relief.


SERVICES

1 We supply machines with battery technology support.

2 We can also supply a full set of materials for lithium battery including polymer battery, cylinder battery, mobile phone battery, EV battery.

3 We can also supply a full set of lithium battery equipment for lab research, pilot scale research and production line.

4 We can also supply a full set of battery technology for battery design, research and producing.
