Lithium Battery Aluminum Laminated Film and Battery Separator Slitting Machine

Max slitting size(mm):650mm

The Lithium battery aluminum laminated film slitting machine with photoelectric tracking correction system, magnetic powder clutch for winding and unwinding tension control, host frequency, cots on activities is controlled by cylinder can also fit, slitting, can also separate joint or separate cutting, accurate slitting, fast slitting speed and operation and maintenance is convenient etc.

Brand:
TOB NEW ENERGY
item no.:
TOB-SL650
order(moq):
1set
Payment:
L/C,T/T
product origin:
China
shipping port:
XIAMEN

inquiry now

Product Detail

Lithium Battery Aluminum Laminated Film, Battery Separator Slitting Machine

SPECIFICATIONS

Model	TOB-SL650
Size(mm)	2400x1700x1300
Weight(kg)	1000
Power supply	AC220V
Power (kw)	2.2
Slitting speed(m/min)	80
Max slitting size(mm)	650
Min slitting size(mm)	8
Feeding roll diameter(mm)	600
Winding roll diameter(mm)	450
Slitting accuracy(mm)	±0.1mm

PRODUCT DISPLAY

film slitting machine
