  • TOB New Energy has Moved to a New Office Location
    TOB New Energy has Moved to a New Office Location Jun 24, 2020
    Dear TOB New Energy Customers, We are proud to announce that we have just moved to a new office location on 24 June, 2020 to accommodate our growth. Our new office address is: Room 111, Building 5th, NO.1633, Jicheng Road, Tong'an torch Industry Phase II, Tong'an District, Xiamen City, Fujian Province, China, 361100 Our office number will remain the same as +86-592-7311160 / +86-18120715609. Our new and larger office space allows us to add more functions to serve our customers better. Should you have any questions on the relocation, please feel free to contact us. TOB New Energy is a company that provide total equipment and materials of lithium battery from electrode preparation to battery assembly, and more important, we also provide corresponding lithium battery technology service to our customer, we can provide a turn key battery project.
    view more
  • Delivery of vacuum oven
    Delivery of vacuum oven Aug 03, 2020
    The vacuum oven plays a particularly important role in the baking of materials, pole pieces, and batteries in the production process of lithium batteries.  It fully removes water and ensures the high performance of the battery. A batch of vacuum oven for the cylindrical lithium battery production line has been completed. They will be sent to the customer's factory soon. Vacuum ovens are widely used in chemical, electronics, food, light industry, medicine, and other industries, and can dry materials under vacuum. It has the advantages of fast drying speed, low pollution and no damage to the internal quality of the dried items. The special vacuum oven for lithium batteries is a vacuum oven specially designed for the baking process of lithium-ion batteries. Its working principle: the boiling point decreases with the decrease of air pressure. The boiling point of water is significantly reduced under negative pressure. When the pressure drops to -0.089Mpa, the theoretical boiling point can be reduced to 45°C. In a negative pressure environment, moisture is easier to vaporize. After the special oven for lithium battery is heated for a period of time under normal pressure, the moisture in the battery or pole piece is converted into water vapor; after the moisture evaporates, vacuum can be used to extract the water vapor; nitrogen is filled to break the vacuum to maintain a dry environment. In the actual baking process, the above three steps are different according to different processes, and generally require multiple cycles. TOB NEW ENERGY LIMITED is specialized in lithium battery industry, our company can provide you a turnkey project, if you are interested in it, feel free to contact us! Contact person:Gavin Zhu (Engineer & Sales) Email:tob.gavin@tobmachine.com Skype: tob.gavin@tobmachine.com Wechat: TOB-007
    view more
  • Delivery of Vacuum Planetary Mixer
    Delivery of Vacuum Planetary Mixer Jul 29, 2020
    A batch of vacuum planetary mixers for the cylindrical lithium battery production line has been completed. They will be packed into 4 containers and sent to the customer's factory. Application fields of lithium battery vacuum planetary mixing machine: fuel cell, power battery, polymer lithium ion battery (LIP), button type lithium battery, lithium iron phosphate battery, electric vehicle battery, lithium power battery, metal hydride nickel battery, mercury-free Alkaline zinc-manganese batteries, lithium (lithium-ion) plastic batteries, electrochemical energy storage supercapacitors, lithium-ion battery slurry. TOB NEW ENERGY LIMITED is specialized in lithium battery industry, our company can provide you a turnkey project, if you are interested in it, feel free to contact us! Contact person:Gavin Zhu (Engineer & Sales) Email:tob.gavin@tobmachine.com Skype: tob.gavin@tobmachine.com Wechat: TOB-007
    view more
  • High-speed and high-precision intelligent extrusion coating machine for lithium battery
    High-speed and high-precision intelligent extrusion coating machine for lithium battery Jul 21, 2020
    Recently we are customizing an extrusion coating machine for a customer for the cylindrical battery production line. The equipment will be completed soon and sent to the customer's factory. The key technology of high-speed, high-precision intelligent lithium battery coating machine mainly includes extrusion coating, fast drying, tension correction and real-time film thickness monitoring feedback closed-loop control. Optimization of extrusion coating die parameters through finite element simulation, using suspension drying technology and aerodynamic design technology to achieve rapid drying, tension correction adopts fully closed loop tension control and fully automatic EPC real-time correction. Comprehensive use of motion control, servo drive, sensors, computer technology and other disciplines and technologies, Realize the multi-functional composite integrated structure of unwinding, deviation correction, tension control, slurry conveying, coating, drying, winding, etc. TOB NEW ENERGY LIMITED is specialized in lithium battery industry, our company can provide you a turnkey project, if you are interested in it, feel free to contact us! Contact person:Gavin Zhu (Engineer & Sales) Email:tob.gavin@tobmachine.com Skype: tob.gavin@tobmachine.com Wechat: TOB-007
    view more
  • Semi-automatic Battery Stacking Machine
    Semi-automatic Battery Stacking Machine Jul 13, 2020
    Today, one semi-automatic battery stacking machine will be sent to our customer, this battery stacking machine will be used for laboratory polymer lithium battery research. The stacking machine is generally composed of ten mechanisms, namely: feeding mechanism, positive electrodes box, negative electrodes box, positive secondary positioning mechanism, negative secondary positioning mechanism, positive electrodes feeding mechanism, negative electrodes feeding mechanism, laminating platform, paste glue mechanism, discharging mechanism. The working principle of the semi-automatic battery stacking machine is to load the positive and negative sheets into the material box, and the manipulator moves left and right to pick up the electrodes in the positive and negative material boxes. After the second positioning, the positive and negative plates are alternately placed on the lamination table . The separator unwinds actively, and the lamination table drives the separator to reciprocate left and right to form a Z-shaped stack. After the lamination is completed, it is cut according to the set length, the battery core is automatically sent out, and the glue is manually applied. By the way, we also have full automatic stacking machine or manual stacking machine, if you are interested in it, feel free to contact me. Thank you for reading! Contact person:Gavin Zhu (Engineer & Sales) Email : tob.gavin@tobmachine.com Skype : tob.gavin@tobmachine.com Wechat : TOB-007
    view more
  • Vacuum Drying Oven and Drying Process
    Vacuum Drying Oven and Drying Process Jul 08, 2020
    The vacuum drying is to put the materials to be dried in an enclosed space, use vacuum equipment to reduce the air pressure in the enclosed space to an atmospheric pressure, and at the same time continuously heat the materials. In this way, the water molecules in the material gradually diffuse to the surface of the material due to the effects of pressure difference and concentration difference. After obtaining sufficient kinetic energy on the surface of the material, the binding of the intermolecular attraction is gradually overcome, and it escapes into the vacuum chamber of low pressure and then passes The vacuum pump is discharged into the atmosphere. Vacuum drying processes: The first is the heat transfer process, the material absorbs heat through the heat source, heats up and vaporizes the internal moisture; Secondly, in the process of liquid mass transfer inside the material, the water inside the material moves to the surface in the form of liquid, and then vaporizes on the surface; Finally, during the gaseous mass transfer process of the moisture on the surface of the material, the water vapor vaporized on the surface of the material gradually escapes into the inside of the vacuum chamber and flows to the outside through the vacuum chamber. To complete the above heat and mass transfer process, temperature, pressure and concentration are the key control factors; Temperature: The temperature of the heat source should be significantly greater than the temperature of the material to meet the energy required for its own temperature increase and vaporization of moisture. The higher the temperature, the faster the drying. Concentration: The so-called concentration refers to the concentration of moisture in the material. The internal concentration of the material is higher than the surface concentration of the material. Under the action of capillary force and concentration difference, it migrates to the surface and eventually reduces the concentration of moisture. Pressure: The steam pressure on the surface of the material is higher than the partial pressure of steam in the drying oven, which is the core theory of vacuum drying. Vacuum drying thermodynamics mainly studies the relationship between the vaporization temperature of water, the saturated vapor pressure and the degree of vacuum. The theoretical basis can be Clapron. Clausius formula expression The vaporization temperature of water is positively correlated with saturated vapor pressure and negatively correlated with vacuum degree. The smaller the saturated vapor pressure, the lower the vaporization temperature of water. Similarly, the greater the vacuum degree, the lower the vaporization temperature of water. Therefore, it can be seen that water is easier to achieve low-temperature vaporization in a vacuum environment. When the temperature is maintained at a certain value, increasing the vacuum in the drying chamber can convert more moisture on the surface of the material into water v...
    view more
  • Ultrasonic Metal Welding Process in Lithium-ion Battery Manufacturing
    Ultrasonic Metal Welding Process in Lithium-ion Battery Manufacturing Jul 01, 2020
    As a key part in the manufacturing process of lithium batteries, the welding process is applied to the connection of multiple positions of lithium battery aluminum/copper anode and cathode current collectors, electrodes, and battery packaging. Any welding joint defects will significantly affect the performance of lithium batteries. consistency. Therefore, it is necessary to understand the ultrasonic welding process. The principle of ultrasonic welding In the ultrasonic welding process, the transducer converts high-frequency electrical signals into ultrasonic vibration signals. High-frequency vibration is transmitted to the surface of the metal to be welded through the welding tool head. The interface metal oxide film is broken under a certain pressure and the intense friction of ultrasonic vibration, clean interface metal contacts and under the combined action of friction and ultrasonic softening, further plastic flow and diffusion will gradually increase the connection area and eventually form a reliable connection. Effect of welding pressure on welding The strength of the welded joint increases with pressure and then decreases. Welding pressure will change the sliding resistance of the welding interface. A small welding pressure will cause a small sliding resistance of the interface, so that the energy generated by the friction is not enough to form an effective connection at the interface; too much welding pressure causes the tool head to be pressed down too deep, welding the interface Metals bite each other, which affects the relative motion of the interface, hinders the further connection of the interface metals, and results in poor mechanical properties of the welded joint. Therefore, proper welding pressure parameters are decisive for welding quality. Effect of time on welding The welding time directly affects the energy input during the welding process and has a direct effect on the welding effect. The welding time is too short and the input energy is insufficient. It is difficult to form an effective solder joint due to insufficient friction; as the welding time increases, the temperature increases due to mutual friction, the workpiece material begins to soften, and the oxide film at the interface of the welding area is damaged and plastically deformed , Can form a better connection; when the welding time is further extended, the welding head is easy to form deep marks on the surface of the workpiece, which will adversely affect the welding effect. In addition, too long welding time will easily cause the welding head and the workpiece to be welded Bonding Effect of amplitude on welding In the ultrasonic welding process, the vibration system formed by the workpiece and the workpiece directly affects the instantaneous velocity of the vibration at the interface of the workpiece, which ultimately affects the friction heat generation and plastic deformation, which affects the welding quality. Contacts: Miss carol(Sales&Engineer) E-mail:to...
    view more
  • High Temperature Vacuum Oven Delivery
    High Temperature Vacuum Oven Delivery Jun 29, 2020
    Today, one set TOB-DZF-6050-HT high temperature vacuum oven has been sent to our USA customer. Applicable scope of high temperature oven: For laboratories and production sites of scientific research units, professional colleges, industrial and mining enterprises and other units, and drying and heat-treating items under vacuum. Heating and drying items under vacuum has the following advantages; ⑴The drying temperature can be reduced. ⑵ Avoid oxidation of some items when heated. ⑶ Avoid heating air to kill biological cells. ⑷No dust damage By the way, we also can supply full set lithium battery equipment and battery materials for lithium battery research or production, if you have any needs, feel free to contact us. Thank you for reading! Contact person:Gavin Zhu (Engineer & Sales) Email:tob.gavin@tobmachine.com Skype: tob.gavin@tobmachine.com Wechat: TOB-007
    view more
  • Five Containers of Pouch Cell Equipment to  Russia
    Five Containers of Pouch Cell Equipment to Russia Jun 19, 2020
    Today after a whole day hard work,we finally finished the five containers equipment for pouch cell pilot line to Russia. Good weather and good project. Pouch cell electrode making is same as other model electrode,it is mainly different at the assembly.From electrode stacking to sealing. Stacking After the production of the electrode, it is transferred to the stacking. The stacking means that the cathode, the separator, and the anode are stacked layer by layer to make a jolly roll. There are two main stacking methods, winding and zigzag stacking. Aluminum laminated film forming Punching, punching is a forming process for Aluminum laminated film. After feeding the aluminum-plastic film, the aluminum-plastic film is deformed through the punching die, and there is a pocket for us to store the core. Pre-sealing There are a total of four packages. The pre-package we mean refers to the top and side seals, leaving a seal to facilitate electrolyte injection. After placing the core in the pit, the entire aluminum-plastic film can be placed in the jig for top sealing and side sealing in the top side sealing machine. When encapsulating, the two heads have a certain temperature (generally around 180 ℃), and when pressed, they are pressed on the aluminum plastic film, and the PP layer of the aluminum plastic film melts and then sticks together. Second-sealing During the second seal, the air bag is punctured by a guillotine and a vacuum is drawn at the same time, so that the gas in the air bag and a small part of the electrolyte will be drawn out. Immediately afterwards, the two sealing heads are encapsulated in the second sealing area to ensure the airtightness of the cell. Finally, cut off the airbags after the packaged cells. After the second airbags are cut, you need to trim and fold the edges. That is, cut the one edge and the second edge to a suitable width, and then fold it to ensure the battery core. The width does not exceed the standard, such a soft-packed battery core is basically formed. We, TOB New Energy ,we are not only provide the battery equipment , but also provide the battery technology. Contacts: Miss carol(Sales&Engineer) E-mail:tob.mae@tobmachine.com Skype:583432443@qq.com Wechat:TOB-005
    view more
  • Lithium Coin Cell Lab Equipment Manufacturer
    Lithium Coin Cell Lab Equipment Manufacturer Jun 15, 2020
    TOB New Eenergy is a professional manufacturer of lithium-ion battery equipment and battery materials, and we can also provide lithium-ion battery technology. Many enterprises, universities, and scientific research institutes have set up a button battery test line for the study of materials. The button battery test line equipment has low cost and simple operation, which is very helpful for beginners to enter the lithium battery industry. By the way, we also can supply full set equipment and materials for cylindrical cell or pouch cell, if you are interested in lithium battery industry, feel free to contact us. Thank you for reading! Contact person:Gavin Zhu (Engineer & Sales) Email:tob.gavin@tobmachine.com Skype: tob.gavin@tobmachine.com Wechat: TOB-007
    view more
  • New Design Single Side Battery Electrode Extrusion Coating Machine
    New Design Single Side Battery Electrode Extrusion Coating Machine Jun 10, 2020
    The battery coating generally refers to a process of uniformly coating the slurry with uniform stirring on the current collector and drying the organic solvent in the slurry. The effect of coating has an important impact on battery capacity, internal resistance, cycle life and safety, ensuring that the electrode are evenly coated. The choice of coating method and control parameters have an important impact on the performance of lithium-ion batteries. This new design single side extrusion coating machine have 3 section oven,and the temperature of each section of the oven can be controlled individually,which can have a better drying effect.If the drying temperature is too low during coating, the electrode cannot be completely dried. If the temperature is too high, the organic solvent inside the electrode may evaporate too quickly, and the surface coating of the pole piece may crack or fall off. And this battery coating machine is adoption slot-die extrusion coating way,this coating way coating effect is good, the coating amount is flexibly controlled by the micro-adjustment of the coating blade, and the coating accuracy is high; it can be coated in a discontinuous mode, and the coating range can be adjusted freely, without the use of a baffle, it will not occur stain phenomenon caused by different edge thickness; easy to clean and disassemble; help to maintain a high level of cleanliness, the channel for the overall flow of glue can be sealed to prevent other contaminants from entering. If you are interesting of this coating machine,you can directly contact us. We are TOB, we are not only provide the equipment of the battery,but also provide the knowledge of battery. Contacts: Miss carol(Sales&Engineer) E-mail:tob.mae@tobmachine.com Skype:583432443@qq.com Wechat:TOB-005
    view more
  • Lithium Coin Cell and Pouch Cell Equipment Shipped to Our Customer
    Lithium Coin Cell and Pouch Cell Equipment Shipped to Our Customer Jun 08, 2020
    These battery production line equipment are used for lithium coin cell and pouch cell battery laboratory research, they are ready to ship to our new Russia customer, this is a new lithium battery research laboratory established by the customer, our company not only provides them with equipment, but also provides them with lithium battery technology support, of course we also will provide them the battery materials, that is, to provide customers with turnkey services. These devices are included vacuum oven, battery coating machine, battery sealing machine, electrode punching machine, glove box, etc. TOB new energy is specialized in lithium battery industry, if you are interested in it, please feel free to contact us. Warmly welcome you to visit our company. Thank you for reading! Contact person:Gavin Zhu (Engineer & Sales) Email:tob.gavin@tobmachine.com Skype: tob.gavin@tobmachine.com Wechat: TOB-007
    view more
  • Installation and commissioning of domestic university laboratory equipment
    Installation and commissioning of domestic university laboratory equipment Jun 01, 2020
    These devices are used for lithium polymer battery laboratory research, all equipment has safely arrived at the university’s laboratory. They will conduct research on lithium battery materials in this laboratory. Today, our team of engineers has also arrived at the laboratory for equipment installation and commissioning, we will teach them how to use the equipment safely, and tell them how to maintain the equipment, etc. TOB new energy is specialized in lithium battery industry, we can supply full set of lithium battery equipment and materials for lab research or battery production line, also we can supply the lithium battery technology, if you are interested in it, please feel free to contact us. Thank you for reading! Contact person:Gavin Zhu (Engineer & Sales) Email:tob.gavin@tobmachine.com Skype: tob.gavin@tobmachine.com Wechat: TOB-007
    view more
  • Lithium Battery Winding Machine
    Lithium Battery Winding Machine May 28, 2020
    According to the operation mode of the machine, the winding machine can be divided into: manual winding machine, semi-automatic winding machine, automatic winding machine. Manual winding machine Manual winding machine is mainly used for laboratory research.It has the following characteristics,easy to operate,have little debug time,and have a cheap price. Semi-auto winding machine This Battery Semi-auto winding machine is used for semi-automatic winding of lithium ion battery cells; suitable for oily electrode, water-based electrode and various separator; 6 characteristics of the equipment 1. Manual loading of electrode, automatic winding, automatic needle change, automatic glue termination tape and automatic discharge; 2. Convenient adjustment of electrode and separator tension; 3. The tension of the electrode and separator is constant, the consistency of the cell is good, and a vacuum suction device is also provided. 4. The equipment is easy to operate and the training time for workers is short; 5. The equipment debugging time is short, the material is saved, and the type adjustment is convenient; 6. Low equipment failure rate and easy maintenance; Automatic winding machine Suitable for automatic winding of round power lithium battery cells. 1. Adopt AC servo motor drive, tension control unwinding, adjustable tension. 2. Unwinding and winding are equipped with correcting device. 3. There is a magnetic cleaning device for the electrode, a static electricity removal device, a dust brushing device, a dust suction device and recycling. 4. Automatic correction, linear guidance and positioning before the electrode is fed into the chuck to ensure the winding quality. 5. The first cathode or anode electrode can be adjusted. 6. It has two methods: separator outer packaging and electrode outer packaging. 7. The detection device monitors the working operation status, if there is any abnormality, it will automatically alarm and shut down. 8. PLC control system, touch screen display, easy to set up and operate. 9. Automatic delivery of finished products with reasonable structure. We are TOB New Energy ,we are not only provide the equipment of the battery,but also provide the knowledge of battery. Contacts: Miss carol(Sales&Engineer) E-mail:tob.mae@tobmachine.com Skype:583432443@qq.com Wechat:TOB-005
    view more
  • Battery Coating and Rolling All-in-one Machine
    Battery Coating and Rolling All-in-one Machine May 25, 2020
    This battery coating and rolling all-in-one machine is a three roller transfer coating equipment, it can carry out continuous and intermittent coating, and then roll with high precision, it is used for surface coating and rolling process of various substrates. This battery electrode coater is very suitable for colleges, scientific research institutes, material manufacturers and other customers, and meet the same coating accuracy as the production design, the speed of coating and rolling is consistent. It has excellent drying effect. It is an ideal choice for the research and development of lithium-ion batteries, super capacitors, nickel batteries and other secondary batteries. This battery coating machine was designed by our engineers for a college laboratory customer, if you are interested in it, or have your own special requirements, please tell us, our engineers will give you a satisfactory solution. Thank you for reading! Contact person:Gavin Zhu (Engineer & Sales) Email : tob.gavin@tobmachine.com Skype : tob.gavin@tobmachine.com Wechat : TOB-007
    view more
  • Brazil Pouch Cell Laboratory Line Arrived and Installation Acceptance
    Brazil Pouch Cell Laboratory Line Arrived and Installation Acceptance May 22, 2020
    After drifting on the sea for some days,our Brazil customer had received our equipment for pouch cell assembly. After a few times installment and debug they are really satisfied our equipment and finished the equipment acceptance.What a beautiful and tidy laboratory! There are two mainstream methods of making the cells of polymer battery, stacking and winding. Battery electrode stacking is through the equipment follow the Z-shape stack the anode and cathode electrode and battery separator together. Our customer adopted is this way. And another is use the winding needle to winding the cathode anode and separator to be a battery cell. Stacking process maybe need some more time, but here also have the advantage that people can not refuse: 1. Low internal resistance,equivalent to multiple small electrode in parallel, reducing internal resistance. 2. High rate discharge capacity,parallel connection of multi-electrode makes it easier to complete large current discharge in a short time. 3. High discharge platform,the internal resistance is lower and the polarization is smaller, so the discharge platform will be higher than the winding battery and closer to the material self-discharge platform. 4. High capacity density,the internal space of the battery is fully utilized, so compared with the winding process, the volume specific capacity is higher. 5. High energy density,the discharge platform and volume specific capacity are higher than the winding process battery, so the energy density is correspondingly higher. 6. Wide range of application,whether it is made into ultra-thin batteries or ultra-thick batteries, the lamination process can be competent. 7. Thickness is easy to control, not easy to deform,the internal structure of the battery cell is consistent, and the thickness of each part of the battery is correspondingly consistent, so it is easy to control its thickness. At the same time, the internal structure is unified, the reaction rate is relatively consistent, even if the thick cell is not easily deformed 8. Flexible size, suitable for high rate batteries, shaped batteries, power batteries, etc.Each electrode size can be designed according to the battery size, so that the battery can be made into any shape. We, TOB New Energy, we are not only provide the equipment of the battery,but also provide the knowledge of battery. Contacts: Miss carol(Sales&Engineer) E-mail:tob.mae@tobmachine.com Skype:583432443@qq.com Wechat:TOB-005
    view more
