Dear TOB New Energy Customers, We are proud to announce that we have just moved to a new office location on 24 June, 2020 to accommodate our growth. Our new office address is: Room 111, Building 5th, NO.1633, Jicheng Road, Tong'an torch Industry Phase II, Tong'an District, Xiamen City, Fujian Province, China, 361100 Our office number will remain the same as +86-592-7311160 / +86-18120715609. Our new and larger office space allows us to add more functions to serve our customers better. Should you have any questions on the relocation, please feel free to contact us. TOB New Energy is a company that provide total equipment and materials of lithium battery from electrode preparation to battery assembly, and more important, we also provide corresponding lithium battery technology service to our customer, we can provide a turn key battery project.

As a key part in the manufacturing process of lithium batteries, the welding process is applied to the connection of multiple positions of lithium battery aluminum/copper anode and cathode current collectors, electrodes, and battery packaging. Any welding joint defects will significantly affect the performance of lithium batteries. consistency. Therefore, it is necessary to understand the ultrasonic welding process. The principle of ultrasonic welding In the ultrasonic welding process, the transducer converts high-frequency electrical signals into ultrasonic vibration signals. High-frequency vibration is transmitted to the surface of the metal to be welded through the welding tool head. The interface metal oxide film is broken under a certain pressure and the intense friction of ultrasonic vibration, clean interface metal contacts and under the combined action of friction and ultrasonic softening, further plastic flow and diffusion will gradually increase the connection area and eventually form a reliable connection. Effect of welding pressure on welding The strength of the welded joint increases with pressure and then decreases. Welding pressure will change the sliding resistance of the welding interface. A small welding pressure will cause a small sliding resistance of the interface, so that the energy generated by the friction is not enough to form an effective connection at the interface; too much welding pressure causes the tool head to be pressed down too deep, welding the interface Metals bite each other, which affects the relative motion of the interface, hinders the further connection of the interface metals, and results in poor mechanical properties of the welded joint. Therefore, proper welding pressure parameters are decisive for welding quality. Effect of time on welding The welding time directly affects the energy input during the welding process and has a direct effect on the welding effect. The welding time is too short and the input energy is insufficient. It is difficult to form an effective solder joint due to insufficient friction; as the welding time increases, the temperature increases due to mutual friction, the workpiece material begins to soften, and the oxide film at the interface of the welding area is damaged and plastically deformed , Can form a better connection; when the welding time is further extended, the welding head is easy to form deep marks on the surface of the workpiece, which will adversely affect the welding effect. In addition, too long welding time will easily cause the welding head and the workpiece to be welded Bonding Effect of amplitude on welding In the ultrasonic welding process, the vibration system formed by the workpiece and the workpiece directly affects the instantaneous velocity of the vibration at the interface of the workpiece, which ultimately affects the friction heat generation and plastic deformation, which affects the welding quality. Contacts: Miss carol(Sales&Engineer) E-mail:to...

Today, one set TOB-DZF-6050-HT high temperature vacuum oven has been sent to our USA customer. Applicable scope of high temperature oven: For laboratories and production sites of scientific research units, professional colleges, industrial and mining enterprises and other units, and drying and heat-treating items under vacuum. Heating and drying items under vacuum has the following advantages; ⑴The drying temperature can be reduced. ⑵ Avoid oxidation of some items when heated. ⑶ Avoid heating air to kill biological cells. ⑷No dust damage By the way, we also can supply full set lithium battery equipment and battery materials for lithium battery research or production, if you have any needs, feel free to contact us. Thank you for reading! Contact person:Gavin Zhu (Engineer & Sales) Email:tob.gavin@tobmachine.com Skype: tob.gavin@tobmachine.com Wechat: TOB-007

Today after a whole day hard work,we finally finished the five containers equipment for pouch cell pilot line to Russia. Good weather and good project. Pouch cell electrode making is same as other model electrode,it is mainly different at the assembly.From electrode stacking to sealing. Stacking After the production of the electrode, it is transferred to the stacking. The stacking means that the cathode, the separator, and the anode are stacked layer by layer to make a jolly roll. There are two main stacking methods, winding and zigzag stacking. Aluminum laminated film forming Punching, punching is a forming process for Aluminum laminated film. After feeding the aluminum-plastic film, the aluminum-plastic film is deformed through the punching die, and there is a pocket for us to store the core. Pre-sealing There are a total of four packages. The pre-package we mean refers to the top and side seals, leaving a seal to facilitate electrolyte injection. After placing the core in the pit, the entire aluminum-plastic film can be placed in the jig for top sealing and side sealing in the top side sealing machine. When encapsulating, the two heads have a certain temperature (generally around 180 ℃), and when pressed, they are pressed on the aluminum plastic film, and the PP layer of the aluminum plastic film melts and then sticks together. Second-sealing During the second seal, the air bag is punctured by a guillotine and a vacuum is drawn at the same time, so that the gas in the air bag and a small part of the electrolyte will be drawn out. Immediately afterwards, the two sealing heads are encapsulated in the second sealing area to ensure the airtightness of the cell. Finally, cut off the airbags after the packaged cells. After the second airbags are cut, you need to trim and fold the edges. That is, cut the one edge and the second edge to a suitable width, and then fold it to ensure the battery core. The width does not exceed the standard, such a soft-packed battery core is basically formed. We, TOB New Energy ,we are not only provide the battery equipment , but also provide the battery technology. Contacts: Miss carol(Sales&Engineer) E-mail:tob.mae@tobmachine.com Skype:583432443@qq.com Wechat:TOB-005

TOB New Eenergy is a professional manufacturer of lithium-ion battery equipment and battery materials, and we can also provide lithium-ion battery technology. Many enterprises, universities, and scientific research institutes have set up a button battery test line for the study of materials. The button battery test line equipment has low cost and simple operation, which is very helpful for beginners to enter the lithium battery industry. By the way, we also can supply full set equipment and materials for cylindrical cell or pouch cell, if you are interested in lithium battery industry, feel free to contact us. Thank you for reading! Contact person:Gavin Zhu (Engineer & Sales) Email:tob.gavin@tobmachine.com Skype: tob.gavin@tobmachine.com Wechat: TOB-007

The battery coating generally refers to a process of uniformly coating the slurry with uniform stirring on the current collector and drying the organic solvent in the slurry. The effect of coating has an important impact on battery capacity, internal resistance, cycle life and safety, ensuring that the electrode are evenly coated. The choice of coating method and control parameters have an important impact on the performance of lithium-ion batteries. This new design single side extrusion coating machine have 3 section oven,and the temperature of each section of the oven can be controlled individually,which can have a better drying effect.If the drying temperature is too low during coating, the electrode cannot be completely dried. If the temperature is too high, the organic solvent inside the electrode may evaporate too quickly, and the surface coating of the pole piece may crack or fall off. And this battery coating machine is adoption slot-die extrusion coating way,this coating way coating effect is good, the coating amount is flexibly controlled by the micro-adjustment of the coating blade, and the coating accuracy is high; it can be coated in a discontinuous mode, and the coating range can be adjusted freely, without the use of a baffle, it will not occur stain phenomenon caused by different edge thickness; easy to clean and disassemble; help to maintain a high level of cleanliness, the channel for the overall flow of glue can be sealed to prevent other contaminants from entering. If you are interesting of this coating machine,you can directly contact us. We are TOB, we are not only provide the equipment of the battery,but also provide the knowledge of battery. Contacts: Miss carol(Sales&Engineer) E-mail:tob.mae@tobmachine.com Skype:583432443@qq.com Wechat:TOB-005

These battery production line equipment are used for lithium coin cell and pouch cell battery laboratory research, they are ready to ship to our new Russia customer, this is a new lithium battery research laboratory established by the customer, our company not only provides them with equipment, but also provides them with lithium battery technology support, of course we also will provide them the battery materials, that is, to provide customers with turnkey services. These devices are included vacuum oven, battery coating machine, battery sealing machine, electrode punching machine, glove box, etc. TOB new energy is specialized in lithium battery industry, if you are interested in it, please feel free to contact us. Warmly welcome you to visit our company. Thank you for reading! Contact person:Gavin Zhu (Engineer & Sales) Email:tob.gavin@tobmachine.com Skype: tob.gavin@tobmachine.com Wechat: TOB-007

These devices are used for lithium polymer battery laboratory research, all equipment has safely arrived at the university’s laboratory. They will conduct research on lithium battery materials in this laboratory. Today, our team of engineers has also arrived at the laboratory for equipment installation and commissioning, we will teach them how to use the equipment safely, and tell them how to maintain the equipment, etc. TOB new energy is specialized in lithium battery industry, we can supply full set of lithium battery equipment and materials for lab research or battery production line, also we can supply the lithium battery technology, if you are interested in it, please feel free to contact us. Thank you for reading! Contact person:Gavin Zhu (Engineer & Sales) Email:tob.gavin@tobmachine.com Skype: tob.gavin@tobmachine.com Wechat: TOB-007

According to the operation mode of the machine, the winding machine can be divided into: manual winding machine, semi-automatic winding machine, automatic winding machine. Manual winding machine Manual winding machine is mainly used for laboratory research.It has the following characteristics,easy to operate,have little debug time,and have a cheap price. Semi-auto winding machine This Battery Semi-auto winding machine is used for semi-automatic winding of lithium ion battery cells; suitable for oily electrode, water-based electrode and various separator; 6 characteristics of the equipment 1. Manual loading of electrode, automatic winding, automatic needle change, automatic glue termination tape and automatic discharge; 2. Convenient adjustment of electrode and separator tension; 3. The tension of the electrode and separator is constant, the consistency of the cell is good, and a vacuum suction device is also provided. 4. The equipment is easy to operate and the training time for workers is short; 5. The equipment debugging time is short, the material is saved, and the type adjustment is convenient; 6. Low equipment failure rate and easy maintenance; Automatic winding machine Suitable for automatic winding of round power lithium battery cells. 1. Adopt AC servo motor drive, tension control unwinding, adjustable tension. 2. Unwinding and winding are equipped with correcting device. 3. There is a magnetic cleaning device for the electrode, a static electricity removal device, a dust brushing device, a dust suction device and recycling. 4. Automatic correction, linear guidance and positioning before the electrode is fed into the chuck to ensure the winding quality. 5. The first cathode or anode electrode can be adjusted. 6. It has two methods: separator outer packaging and electrode outer packaging. 7. The detection device monitors the working operation status, if there is any abnormality, it will automatically alarm and shut down. 8. PLC control system, touch screen display, easy to set up and operate. 9. Automatic delivery of finished products with reasonable structure. We are TOB New Energy ,we are not only provide the equipment of the battery,but also provide the knowledge of battery. Contacts: Miss carol(Sales&Engineer) E-mail:tob.mae@tobmachine.com Skype:583432443@qq.com Wechat:TOB-005

This battery coating and rolling all-in-one machine is a three roller transfer coating equipment, it can carry out continuous and intermittent coating, and then roll with high precision, it is used for surface coating and rolling process of various substrates. This battery electrode coater is very suitable for colleges, scientific research institutes, material manufacturers and other customers, and meet the same coating accuracy as the production design, the speed of coating and rolling is consistent. It has excellent drying effect. It is an ideal choice for the research and development of lithium-ion batteries, super capacitors, nickel batteries and other secondary batteries. This battery coating machine was designed by our engineers for a college laboratory customer, if you are interested in it, or have your own special requirements, please tell us, our engineers will give you a satisfactory solution. Thank you for reading! Contact person:Gavin Zhu (Engineer & Sales) Email : tob.gavin@tobmachine.com Skype : tob.gavin@tobmachine.com Wechat : TOB-007

After drifting on the sea for some days,our Brazil customer had received our equipment for pouch cell assembly. After a few times installment and debug they are really satisfied our equipment and finished the equipment acceptance.What a beautiful and tidy laboratory! There are two mainstream methods of making the cells of polymer battery, stacking and winding. Battery electrode stacking is through the equipment follow the Z-shape stack the anode and cathode electrode and battery separator together. Our customer adopted is this way. And another is use the winding needle to winding the cathode anode and separator to be a battery cell. Stacking process maybe need some more time, but here also have the advantage that people can not refuse: 1. Low internal resistance,equivalent to multiple small electrode in parallel, reducing internal resistance. 2. High rate discharge capacity,parallel connection of multi-electrode makes it easier to complete large current discharge in a short time. 3. High discharge platform,the internal resistance is lower and the polarization is smaller, so the discharge platform will be higher than the winding battery and closer to the material self-discharge platform. 4. High capacity density,the internal space of the battery is fully utilized, so compared with the winding process, the volume specific capacity is higher. 5. High energy density,the discharge platform and volume specific capacity are higher than the winding process battery, so the energy density is correspondingly higher. 6. Wide range of application,whether it is made into ultra-thin batteries or ultra-thick batteries, the lamination process can be competent. 7. Thickness is easy to control, not easy to deform,the internal structure of the battery cell is consistent, and the thickness of each part of the battery is correspondingly consistent, so it is easy to control its thickness. At the same time, the internal structure is unified, the reaction rate is relatively consistent, even if the thick cell is not easily deformed 8. Flexible size, suitable for high rate batteries, shaped batteries, power batteries, etc.Each electrode size can be designed according to the battery size, so that the battery can be made into any shape. We, TOB New Energy, we are not only provide the equipment of the battery,but also provide the knowledge of battery. Contacts: Miss carol(Sales&Engineer) E-mail:tob.mae@tobmachine.com Skype:583432443@qq.com Wechat:TOB-005

Lithium battery fixture is an indispensable tool in the PACK production process, it makes the battery arrangement more neat, and the battery spot welding position of the nickel sheet is also more accurate, to make the performance of the battery pack better. Our engineers will design the battery pack fixture based on your battery pack information, the cost of the fixture is low, and the quality is good. By the way, our company can also provide a variety of battery PACK spot welding machines. If you are interested in it, feel free to contact me. Thank you for reading! Contact person:Gavin Zhu (Engineer & Sales) Email:tob.gavin@tobmachine.com Skype: tob.gavin@tobmachine.com Wechat: TOB-007

The battery pilot line refers to the medium-scale production line before the formal mass production, and has the test function of improving observation. Best battery equipment quality and high-quality sales service are the basis to win customers' trust. We are constantly signing contracts with new companies. This is a batch of new battery equipment, it is for cylindrical cell and pouch cell pilot line. They are about to be packaged and will be sent to our Russian customers soon. If you are interested in lithium-ion battery sector, feel free to contact me, our company can supply full set of battery equipment and battery materials for lab line or production line. We can provide "one-stop" solution and a "Turn key" project for you. Thanks for your reading! Contact person:Gavin Zhu (Engineer & Sales) Email:tob.gavin@tobmachine.com Skype: tob.gavin@tobmachine.com Wechat: TOB-007

The manufacture of lithium-ion batteries is a process in which the process steps are closely linked. Overall, the production of lithium batteries includes the manufacturing process of the electrode, the battery assembly process, and the final electrolyte injection, battery case sealing, battery formation, and aging processes. In the three-stage process, each process can be divided into several key processes, each step will have a great impact on the final performance of the battery. The concept of formation is to charge and discharge a small current to the manufactured lithium ion battery. After the lithium battery is manufactured, it is necessary to charge and discharge the battery with a small current. there are mainly two purpose of pre-charging. After the battery is fabricated, the electrode material is not in the best applicable state, or the physical properties are not suitable (such as too large particles, the contact is not close, etc.), or the phase itself is wrong (such as some metal oxide anodes with alloy mechanism), requires first charge and discharge to activate. During the first charge of the lithium battery, Li + is released from the cathode active material, passes through the electrolyte-separator-electrolyte, and is inserted between the layers of the anode graphite material. We are TOB New Energy, we are not only provide the equipment of the battery,but also provide the knowledge of battery. Contacts: Miss carol(Sales&Engineer) E-mail:tob.mae@tobmachine.com Skype:583432443@qq.com Wechat:TOB-005

18650 lithium-ion battery is one of the most common lithium-ion batteries on the market today. Cylindrical batteries commonly used in battery PACK, that is, people often say 18650, 21700, 32650 and other specifications batteries. The 18650 lithium ion battery pack process is mainly based on the PACK battery structure. Most of the 18650 lithium battery pack process features are similar. TOB New Energy can supply the automatic 18650 battery pack double side spot welding machine for 18650,26650,32650 cylinder battery pack automatic spot welding, it can weld both side together with high speed and good effect. What should be paid attention to when welding 18650 lithium ion battery pack process? 1. Pay attention to the spot welding current when welding 18650 lithium ion battery. 2. Pay attention to the diameter of the welding pin when welding 18650 lithium ion battery. 3. When welding 18650 lithium-ion batteries, pay attention to the distance between the welding pins. 4. When welding 18650 lithium-ion battery pack process, pay attention to the number of welding points. 5. Can not explode fire, short circuit, or virtual welding during spot welding. Multi-parallel multi-series 18650 lithium ion battery pack design process skills 1. Adopt the principle of priority and easy operation, that is, employees are easy to operate. 2. Adopt the principle of priority operation safety, that is, employees are not easy to short-circuit or have better preventive measures during operation. 3. Adopt the principle of equipment, that is, use auxiliary equipment to complete as little as possible, and at least semi-automatic. 4. The packaging design should be reasonable, easy to take and put, and don't take the product out to the customer for a long time. There are many reasons for the inconsistency of the 18650 lithium-ion battery before PACK. The materials constituting the battery are not completely consistent, and the process of manufacturing the battery cannot be controlled to the same degree in every detail. This will lead to inconsistent capacity, inconsistent terminal voltage, inconsistent internal resistance, inconsistent life, etc. In addition to the electrical performance to be screened, the appearance of the 18650 lithium-ion battery should also be tested. For example, measuring defects such as scratches, breakages, stains, pits, bumps on the surface of the battery will affect the assembly of the battery module and the safety characteristics of the pack. We are TOB New Energy,we are not only provide the equipment of the battery,but also provide the knowledge of battery. Contacts: Miss carol(Sales&Engineer) E-mail:tob.mae@tobmachine.com Skype:583432443@qq.com

Polymer batteries are also called lithium polymer batteries (Li-polymer), also known as polymer lithium batteries. It is also a kind of lithium ion battery, but it has many obvious advantages compared with liquid lithium battery (Li-ion), such as high energy density, more compact, ultra-thin, lightweight, and high safety. A new type of battery. In shape, the lithium polymer battery has ultra-thin characteristics, and can be made into batteries of any shape and capacity to meet the needs of various products. The minimum thickness of this type of battery can reach 0.5mm. Its nominal voltage is the same as Li-ion's nominal voltage of 3.7V, with no memory effect. A few months ago, customers came to our company to discuss the details with our engineers. They compared with some suppliers and finally chose to cooperate with our company. All equipment of the polymer pilot line is ready today, and they will be sent to our Russian customers soon. If you are interested in lithium ion battery indsutry, feel free to contact me, our company can supply full set of equipment and materials for lab line or production line. We can provide "one-stop" solution and a "Turn key" project for you. Thank you for reading! Contact person:Gavin Zhu (Engineer & Sales) Email:tob.gavin@tobmachine.com Skype: tob.gavin@tobmachine.com Wechat: TOB-007
