As people explore about the new energy,lithium battery become an increasingly hot topic.And battery performance is most important. And the performance of the battery is determined by some parameters : Battery capacity,battery internal resistance,voltage,discharge platform time,charge and discharge ratio,self-discharge rate and cycle life etc. So,it is need a machine to help us to test and analysis about our battery---battery tester. The battery tester is essential for our battery research,and different battery need different model tester. If you are research about the coin cell,we have the test range from 5V1mA to 5V50mA coin cell tester to satisfied your requirement. And if you a research about cylindrcal battery or pouch cell,we can also provide you the tester about these battery, the follow one is a conventional tester for single cylinder battery of pouch cell 5V6A tester,and if you want test about the pouch cell,connect these clamp to the tester,and you can do it. If you are do about the battery pack testing,we also have related tester for it. And if you are a factory and have a lot of battery,we can also provide you satisfied product. We are TOB New Energy ,we are not only provide the materials of the battery,but also provide the knowledge of battery. Contacts: Miss carol(Sales&Engineer) E-mail:tob.mae@tobmachine.com Skype:583432443@qq.com Wechat:TOB-005

Lithium battery pack process design purpose: safety, quality, efficiency. Key parameters of process design: performance, size(batteries size, guard plate size, complementary makings size, finished products size) Porcess design: development phase, trial production, mass production stage. Lithium battery pack major process: 1. Battery appearance inspection 2. Stick battery surface pad 3. Batteries voltage and internal resistance testing 4. Batteries combination 5. Soldering 6. Spot welding 7. Stick insulation tape 8. PVC film heat shrink 9. Install battery plastic shell, plastic frame 10. Ultrasonic pressing 11. Spraying the code 12. Labelling 13. Performance testing 14. Finished products appearance checking 15. Packaging TOB New Energy can design the whole line according to your requirements, we can supply you manual 18650 lithium battery pack line, automatic 18650 lithium battery pack assembly line, etc. If you are interested in it, feel free to contact me. Contact person:Gavin Zhu (Engineer & Sales) Email:tob.gavin@tobmachine.com Skype: tob.gavin@tobmachine.com Wechat: TOB-007

Today we had finished the package of the vacuum planetary mixer for our Russia customer.The mixing machine is used for lithium battery slurry mixing. The preparation of the battery electrode slurry is the most critical part of the whole process. The quality of the electrode slurry directly affects whether the next step can be performed. Slurry preparation is a non-Newtonian high-viscosity fluid formed by mixing powders and liquids such as living materials, adhesives, solvents, and thickeners. The fluid needs to have a certain viscosity, good fluidity, and a sufficiently small particle size. What kind of equipment does the electrode slurry preparation need to meet the requirements? Have a good vacuum-tight system There are three main reasons why a mixer needs a good vacuum-tight system: ① During the whole mixing process, due to frequent collision and friction between materials, and friction between the agitator and the material, more heat will be generated, resulting in temperature rise. Increasing temperature will cause some solvents to be emitted, which will produce great irritating odors, such as NMP, PVDF, etc. Organic gas will cause great harm to human body. ②In the dry powder premixing stage, if the closed system is not good enough, it will cause dust to rise, destroy the working environment, affect product quality and cause harm to employees. ③ There are large voids inside the powder. After mixing with the solvent, there will be many air bubbles inside the slurry. The slurry needs to be defoamed in order to perform electrode coating, otherwise bubbles will break during the coating process, the areal density is different, and even the foil is exposed, which is extremely detrimental to the battery performance. The material of the mixer has strong corrosion resistance, wear resistance and stable physical and chemical properties Obviously, regardless of the strong alkalinity of the positive electrode material, the strong corrosion resistance of NMP, etc., the mixer needs to have excellent corrosion resistance. During the stirring process, the continuous stirring of the powder by the agitator requires that it has abrasion resistance and a sufficiently long service life. The mixing blade structure is reasonable and the design of the stirring speed meets the requirements In addition to having sufficient stirring power and stirring range in the mixer, the shape and mechanical design of the blades of the mixer have a great influence on the preparation of the slurry. First, it is necessary to ensure that the stirring range of the stirrer is large enough and there is no dead angle in the stirring container. At present, larger-shaft mixers use biaxial or even triaxial planetary agitators to ensure that no powder or agglomerated living materials are not uniformly mixed into the slurry. Secondly, the shape design of the mixer has an absolute impact on the dispersion, mixing, particle size distribution, and fluidity of the material. At present, the c...

The research of coin cell technology mainly includes paste formulation, electrode making, coin cell assembly and coin cell sealing. 1. Paste formulation:Mix a certain proportion of the active material conductive agent and the binder into the mixer and mixing according to a certain process specification. 2. Electrode making:The manufacturing process of the pole piece has a great influence on the performance of the battery. The basic process is ①coating:use coating machine to uniformly coat the slurry on the current collector ②Baking:put the pole pieces in an oven at a certain temperature to remove the water or NMP ③Pressing:put the electrode after baking at the pressing machine to press it ④Punching:use punching machine to make the electrode to a small round 3. Battery assembly process:Place in the order of cathode, separator, spring, and spacer,and then filling the electrolyte in a glove box filled with inert gas.Then cover the anode case. 4. Sealing:Using the coin cell sealing machine sealing the coin cell. We are TOB ,we are not only provide the materials of the battery,but also provide the knowledge of battery. Contacts: Miss carol(Sales&Engineer) E-mail:tob.mae@tobmachine.com Skype:583432443@qq.com Wechat:TOB-005

SBR binder materials is the most widely used water-based binder. It is very soluble in water and polar solvents. It has high bonding strength and good mechanical stability and operability. It is used as battery binder materials in the lithium battery industry. The binding effect is good and the quality is stable. TOB New Energy can supply full set of battery materials for lithium battery lab research or production line, if you are interested in it, feel free to contact me. Contact person:Gavin Zhu (Engineer & Sales) Email:tob.gavin@tobmachine.com Skype: tob.gavin@tobmachine.com Wechat: TOB-007

Every year in March and September, it is alibaba's shopping carnival for international buyers, and it is also our time for tob to participate in orange battle. However, march of this year is a little different, because of the global impact of the coronavirus, this year we also began a different journey, we continue to enrich ourselves online, in order to return to work to better serve our customers for their lithium battery development planning. Since February 3rd, we TOB New Energy started to work online, providing our customers with the best quality services related to the lithium battery industry with our most professional knowledge. Up to now, we have started to deliver goods to customers in a regular manner to ensure that the normal work plan of customers will not be affected. We are TOB NEW ENERGY, we are not only provide the battery equipment and materials we will also provide the knowledge of the battery. Contacts: Miss carol(Sales&Engineer) E-mail:tob.mae@tobmachine.com Skype:583432443@qq.com Wechat:TOB-005

Our produce of the battery electrode copper foil is normally in progress. It is used for lithium battery electrode. The less thickness is 8um. And the width is customize. And we both had the single-side smooth copper foil and double-side smooth copper foil. The rough side copper foil have a bigger adhesion. If you are interesting about the lithium battery copper foil please fill free to contact us. We are TOB New Energy , we are not only provide the battery equipment and materials we will also provide the knowledge of the battery. Contacts: Miss carol(Sales&Engineer) E-mail:tob.mae@tobmachine.com Skype:583432443@qq.com Wechat:TOB-005

Battery coating process is generally refers to the slurry evenly stirred evenly coated on the fluid collection, and drying the organic in the slurry.The effect coating have a big influence for battery capacity, internal resistance, cycle life and safety, to ensure the uniform coating.The choice of coating method and control parameters have an important impact on the performance of lithium ion batteries, mainly in the following aspects: 1) coating drying temperature control: if the coating drying temperature is too low, it can not ensure that the electrode is completely dry, if the temperature is too high, it may be because of the organic solvent inside the electrode evaporation too fast, the surface coating on the electrode cracks, falls off and other phenomena; 2) coating surface density: if the coating surface density is too small, the battery capacity may not reach the nominal capacity; if the coating surface density is too large, it is likely to cause waste of ingredients. In case of serious excess anode capacity, lithium dendrite punctures the battery membrane, resulting in a short circuit, causing potential safety hazards; 3) coating size: coating size is too small or too large may lead to the anode cannot be completely cathode around inside the battery, in the process of charging, lithium ion from the positive embedded, moved to the electrolyte is not cathode completely encase, cannot efficiently exert the anode real capacity, serious, lithium inside the battery will form the dendrite, easily pierced diaphragm lead to circuit inside the battery; 4) coating thickness: if the coating thickness is too thin or too thick, it will affect the subsequent pole rolling process, and the performance consistency of the battery electrode cannot be guaranteed. In addition, the electrode coating is of great significance to the safety of batteries.Before coating, 5S work should be done to ensure that no particles, debris, dust, etc. are mixed into the coating process. If mixed with debris, it will cause a small short circuit inside the battery, which will cause the battery to catch fire and explode seriously. Our battery coating machine can accuracy to achieve the parameter that you need to ensure of the requirement of your battery. We are TOB , we are not only provide the battery equipment and materials we will also provide the knowledge of the battery. Contacts: Miss carol(Sales&Engineer) E-mail:tob.mae@tobmachine.com Skype:583432443@qq.com Wechat:TOB-005
