Patent CN221343111U - Composite Film Forming Device Nov 03, 2026GRANTED UTILITY MODEL · CN221343111U · ACTIVE Patent CN221343111U - Composite Film Forming Device Three supply rollers on a rotating carrier index a fresh roll into the infeed the moment one runs out, so electrode-and-separator composite film forming never stops for reloading. Full specification and drawings: CN221343111U on Google Patents Reviewed by Dany Huang, Ph.D., Founder & CEO, TOB NEW ENERGY | Last updated: 3 November 2026 Laminated (stacked) lithium-ion batteries are built from composite film in which electrode sheets and separator are thermally bonded - the layers are stacked, heated and pressed between rolls. But the specification of CN221343111U records the production bottleneck in that process: each material web was unwound from a single supply roller, and when the roll ran out the whole line had to be stopped for reloading, holding back production progress. CN221343111U, filed on 18 December 2023 and granted on 16 July 2024, answers with a turret-style feeding structure. A rotating carrier plate holds three material rollers in the working embodiment; each roller carries its own supply roll. When one roll runs out, a first driving member turns the plate and the next full roll swings into the machine infeed - reel changeover without stopping the forming line. Patent Information Publication number CN221343111U Title (original) 一种用于生产锂电池复合膜的成型装置 (Composite Film Forming Device with Turret Unwinder) Inventors Huang Zhengyao (Dany Huang); Chen Lucai (Tobey Chen) Current assignee XIAMEN TOB NEW ENERGY TECHNOLOGY Co., Ltd. - the registered entity of TOB NEW ENERGY Filing date 18 December 2023 Grant date 16 July 2024 Document type Utility model (kind code U) Legal status Active Anticipated expiration 18 December 2033 Drawings 4 figures Official record Google Patents - CN221343111U About titles and terminology on this page. The English title above is a human-reviewed translation by TOB NEW ENERGY's engineering team, standardised to the terminology used across our equipment line; it is not a machine rendering. The original Chinese title and claims are the authoritative text - a reader comparing this page with Google Patents may notice wording differences precisely because the public record there is machine-translated. Figures and mechanism descriptions on this page are drawn from the Chinese specification and claims, not from any translation of them. A note on patent type. This is a Chinese utility model patent, which protects the mechanical structure of a device rather than a chemical formulation or process. Utility models carry a ten-year term and are examined for novelty and practical applicability. What follows is therefore a structural description - the claims define an apparatus, and the specification does not publish measured performance figures. Any throughput or tolerance numbers for TOB's production machines come from our equipment datasheets, not from this patent document. Who holds this patent. CN221343111U is a granted Chinese util...view more
-
Patent CN215696773U - Three-Roll Electrode Calender Oct 28, 2026GRANTED UTILITY MODEL · CN215696773U · ACTIVE Patent CN215696773U - Three-Roll Electrode Calender Three press rolls arranged as a triangle, continuous brush-and-filter roll cleaning, and a glue-start take-up synchronized with the calender - the structurally stable electrode rolling patent behind TOB roller presses. Full specification and drawings: CN215696773U on Google Patents Reviewed by Dany Huang, Ph.D., Founder & CEO, TOB NEW ENERGY | Last updated: 28 October 2026 Roll pressing is an indispensable step in manufacturing lithium battery electrode sheets. But the specification of CN215696773U states the problem bluntly: the roller presses then in use for electrode sheets are often structurally unstable, and during rolling an unstable press can damage the electrode sheet and waste raw material. Instead of adding more bracing to a single-nip machine, this patent changes the geometry of the roll set itself. CN215696773U, filed on 2 September 2021 and granted on 1 February 2022, arranges three press rolls in a triangle - two lower rolls on the workbench and a third roll carried in a liftable calender cover above them. Around that triangle it adds roll-surface cleaning, a synchronized take-up and matched height limiting at both ends of the pass, so the electrode is rolled flat, clean and under steady tension. Patent Information Publication number CN215696773U Title (original) 一种结构稳定的锂电池极片辊压机 (Triangular Three-Roll Electrode Calender) Inventors Huang Zhengyao (Dany Huang); Chen Lucai (Tobey Chen) Current assignee XIAMEN TOB NEW ENERGY TECHNOLOGY Co., Ltd. - the registered entity of TOB NEW ENERGY Filing date 2 September 2021 Grant date 1 February 2022 Document type Utility model (kind code U) Legal status Active Anticipated expiration 1 September 2031 Drawings 6 figures Official record Google Patents - CN215696773U About titles and terminology on this page. The English title above is a human-reviewed translation by TOB NEW ENERGY's engineering team, standardised to the terminology used across our equipment line; it is not a machine rendering. The original Chinese title and claims are the authoritative text - a reader comparing this page with Google Patents may notice wording differences precisely because the public record there is machine-translated. Figures and mechanism descriptions on this page are drawn from the Chinese specification and claims, not from any translation of them. A note on patent type. This is a Chinese utility model patent, which protects the mechanical structure of a device rather than a chemical formulation or process. Utility models carry a ten-year term and are examined for novelty and practical applicability. What follows is therefore a structural description - the claims define an apparatus, and the specification does not publish measured performance figures. Any throughput or tolerance numbers for TOB's production machines come from our equipment datasheets, not from this patent document. Who holds this patent. CN215696773...view more
-
Patent CN215656472U - Sorter with Anti-Clogging Feeder Oct 27, 2026GRANTED UTILITY MODEL · CN215656472U · ACTIVE Patent CN215656472U - Sorter with Anti-Clogging Feeder Finished cylindrical cells are fed jam-free through anti-clogging plates and a wheel-type filler, graded by internal resistance, then pushed by air cylinders into the right grade bin. Full specification and drawings: CN215656472U on Google Patents Reviewed by Dany Huang, Ph.D., Founder & CEO, TOB NEW ENERGY | Last updated: 27 October 2026 When cylindrical batteries leave the production line they have to be sorted into quality grades and collected separately. The specification of CN215656472U is blunt about the failure of the conventional way: sorting easily suffered from battery clogging, which pushed up the sorting reject rate. If the feeding stage jams, nothing downstream can be graded correctly. The patent answers at the point where clogging happens - the feed. Two anti-clogging plates and a motor-driven wheel-type filler turn a simple hopper into a controlled, jam-free feeder, an internal-resistance detector grades each cell before it enters the conveyor, and four air cylinders route every cell to the bin of its grade. Patent Information Publication number CN215656472U Application number CN202122170781.7U Title (original) 一种带有防堵装置的电池分选机 (Battery Sorting Machine with Anti-Clogging Feeder) Inventors Huang Zhengyao (Dany Huang); Chen Lucai (Tobey Chen) Current assignee XIAMEN TOB NEW ENERGY TECHNOLOGY Co., Ltd. - the registered entity of TOB NEW ENERGY Filing date 9 September 2021 Grant date 28 January 2022 Document type Utility model (kind code U) Legal status Active Anticipated expiration 9 September 2031 Drawings 6 figures Official record CN215656472U on Google Patents Ownership. TOB NEW ENERGY holds this granted utility model. It was filed under the company's registered Chinese entity (rendered in the page source and structured data) and is co-invented by Dany Huang (Zhengyao Huang) and Tobey Chen. About titles and terminology on this page. The English title above is a human-reviewed translation by TOB NEW ENERGY's engineering team, standardised to the terminology used across our equipment line; it is not a machine rendering. The original Chinese title and claims are the authoritative text - a reader comparing this page with Google Patents may notice wording differences precisely because the public record there is machine-translated. In particular, the machine-translated record of this patent renders the Chinese word for sorter as "separator"; this page uses sorting machine / sorter. Figures and mechanism descriptions on this page are drawn from the Chinese specification and claims, not from any translation of them. A note on patent type. This is a Chinese utility model patent, which protects the mechanical structure of a device rather than a chemical formulation or process. Utility models carry a ten-year term and are examined for novelty and practical applicability. What follows is therefore a structural description - the claims define an a...view more
-
Patent CN215612935U - Liftable Heating & Dehumidifying Unit Oct 26, 2026GRANTED UTILITY MODEL · CN215612935U · ACTIVE Patent CN215612935U - Liftable Heating & Dehumidifying Unit A mobile, electrically liftable unit that heats the coating machine exactly where it works - and condenses moisture out of the air so the heater stays dry and rust-free. Full specification and drawings: CN215612935U on Google Patents Reviewed by Dany Huang, Ph.D., Founder & CEO, TOB NEW ENERGY | Last updated: 26 October 2026 A coating machine's working temperature is not a comfort issue - the specification says temperature has a great influence on the working efficiency of the coating machine, and that poor heating can seriously waste lithium battery production materials. Yet heating a web coating line is not the same as heating a room: the heat must reach the machine at the right height, at the right moment, without being dragged down by the humid air that a coating and drying process constantly releases. CN215612935U, filed on 1 September 2021, answers with a self-contained unit that can be wheeled to any point of the line. Its electric cylinder lowers the heating frame to the working height, an electric heating tube heats the coating machine while it runs, and a cross-flow fan draws the humid air through a moisture-condensing plate - so the heating element is never soaked, never rusted, and never idle. Patent Information Publication number CN215612935U Title (original) 一种用于锂电池涂布机的可升降加热装置 (Liftable Heating & Dehumidifying Unit for Coaters) Inventors Huang Zhengyao (Dany Huang); Chen Lucai (Tobey Chen) Current assignee XIAMEN TOB NEW ENERGY TECHNOLOGY Co., Ltd. - the registered entity of TOB NEW ENERGY Filing date 1 September 2021 Grant date 25 January 2022 Document type Utility model (granted, kind code U) Legal status Active Anticipated expiration 1 September 2031 Drawings 6 figures About titles and terminology on this page. The English title above is a human-reviewed translation by TOB NEW ENERGY's engineering team, standardised to the terminology used across our equipment line; it is not a machine rendering. The original Chinese title and claims are the authoritative text - a reader comparing this page with Google Patents may notice wording differences precisely because the public record there is machine-translated. Figures and mechanism descriptions on this page are drawn from the Chinese specification and claims, not from any translation of them. A note on patent type. This is a Chinese utility model patent, which protects the mechanical structure of a device rather than a chemical formulation or process. Utility models carry a ten-year term and are examined for novelty and practical applicability. What follows is therefore a structural description - the claims define an apparatus, and the specification does not publish measured performance figures. Any throughput or tolerance numbers for TOB's production machines come from our equipment datasheets, not from this patent document. The Production Problem This Patent Solves Coating machin...view more
-
Patent CN215610864U - Large-Capacity Vacuum Slurry Mixer Oct 23, 2026GRANTED UTILITY MODEL · CN215610864U · ACTIVE Patent CN215610864U - Large-Capacity Vacuum Slurry Mixer A lift-and-seal twin-barrel vacuum mixer whose three stirring-rod sets, wall scrapers and stage-controlled speed turn battery raw materials into a fully dispersed electrode slurry. Full specification and drawings: CN215610864U on Google Patents Reviewed by Dany Huang, Ph.D., Founder & CEO, TOB NEW ENERGY | Last updated: 23 October 2026 In lithium-ion battery production, the mixing and dispersion of the cell slurry determines more than 30% of final product quality - the specification calls it the most important link in the entire production process. Yet the mixers in use delivered only an average stirring effect: under-dispersed active particles travel unevenly between the two electrodes, and that unevenness follows the slurry all the way into the coated electrode, the dried coating and finally cell capacity and cycle life. CN215610864U, filed on 26 August 2021, attacks the problem at the machine level: a vacuum mixer whose slurry chamber is sealed by lifting one barrel onto another, whose stirrer combines three sets of stirring rods with three wall-scraping bars, and whose reducer lets the controller assign a different stirring speed to each stage of the batch. Patent Information Publication number CN215610864U Title (original) 一种搅拌效果好的大型电池原料搅拌机 (Large-Capacity Vacuum Slurry Mixer) Inventors Huang Zhengyao (Dany Huang); Chen Lucai (Tobey Chen) Current assignee XIAMEN TOB NEW ENERGY TECHNOLOGY Co., Ltd. - the registered entity of TOB NEW ENERGY Filing date 26 August 2021 Grant date 25 January 2022 Document type Utility model (granted, kind code U) Legal status Active Anticipated expiration 26 August 2031 Drawings 6 figures About titles and terminology on this page. The English title above is a human-reviewed translation by TOB NEW ENERGY's engineering team, standardised to the terminology used across our equipment line; it is not a machine rendering. The original Chinese title and claims are the authoritative text - a reader comparing this page with Google Patents may notice wording differences precisely because the public record there is machine-translated. Figures and mechanism descriptions on this page are drawn from the Chinese specification and claims, not from any translation of them. A note on patent type. This is a Chinese utility model patent, which protects the mechanical structure of a device rather than a chemical formulation or process. Utility models carry a ten-year term and are examined for novelty and practical applicability. What follows is therefore a structural description - the claims define an apparatus, and the specification does not publish measured performance figures. Any throughput or tolerance numbers for TOB's production machines come from our equipment datasheets, not from this patent document. The Production Problem This Patent Solves Cathode slurry is built from binder, conductive agent and cathode material; anode ...view more
-
Patent CN215600399U - Electrode Winder with Hot Knife Oct 22, 2026GRANTED UTILITY MODEL · CN215600399U · ACTIVE Patent CN215600399U - Electrode Winder with Hot Knife Align, transport, heat-soften, wind and hot-cut a finished electrode strip on one machine - one operator runs the whole step. Full specification and drawings: CN215600399U on Google Patents Reviewed by Dany Huang, Ph.D., Founder & CEO, TOB NEW ENERGY | Last updated: 22 October 2026 The electrode is the carrier on which a battery charges and discharges - the core of the whole lithium-ion cell. Its manufacture runs from pulping through precision coating, calendering and slitting into strips, on equipment that involves high rolling force, slitting knives, heat and rotating mechanisms. Yet within that chain the winding of the finished electrode strip was an underestimated bottleneck: the specification states plainly that the influence of electrode-side technology such as the winding process is often underrated, and that the process suffered from low efficiency. CN215600399U, filed on 9 September 2021, turns winding from a manual chore into a single controlled operation. The machine aligns the strip vertical, feeds it through soft-gripped roller sets, heat-softens it for a tight wrap, winds it on a powered platform, and - when the coil is strapped - severs it with a hot cutting blade. One operator, one machine, no separate cutting station. Patent Information Publication number CN215600399U Title (original) 一种用于电池生产的电池极片卷绕机 (Electrode Winder with Integrated Hot Knife) Inventors Huang Zhengyao (Dany Huang); Chen Lucai (Tobey Chen) Current assignee XIAMEN TOB NEW ENERGY TECHNOLOGY Co., Ltd. - the registered entity of TOB NEW ENERGY Filing date 9 September 2021 Grant date 21 January 2022 Document type Utility model (granted, kind code U) Legal status Active Anticipated expiration 9 September 2031 Drawings 6 figures About titles and terminology on this page. The English title above is a human-reviewed translation by TOB NEW ENERGY's engineering team, standardised to the terminology used across our equipment line; it is not a machine rendering. The original Chinese title and claims are the authoritative text - a reader comparing this page with Google Patents may notice wording differences precisely because the public record there is machine-translated. Figures and mechanism descriptions on this page are drawn from the Chinese specification and claims, not from any translation of them. A note on patent type. This is a Chinese utility model patent, which protects the mechanical structure of a device rather than a chemical formulation or process. Utility models carry a ten-year term and are examined for novelty and practical applicability. What follows is therefore a structural description - the claims define an apparatus, and the specification does not publish measured performance figures. Any throughput or tolerance numbers for TOB's production machines come from our equipment datasheets, not from this patent document. The Production Problem This Patent Solves...view more
-
Patent CN215587201U - Battery Sorter with Pressure Sensing Oct 20, 2026GRANTED UTILITY MODEL · CN215587201U · ACTIVE Patent CN215587201U - Battery Sorter with Pressure Sensing Cells ride in pressure-sensing detection bases along a conveyor; an electric cylinder with a rubber pusher diverts rejects into a sorting box - and an emergency-stop bolt can lock the drive shaft. Full specification and drawings: CN215587201U on Google Patents Reviewed by Dany Huang, Ph.D., Founder & CEO, TOB NEW ENERGY | Last updated: 20 October 2026 After a battery is produced it still has to be checked - and in the prior art that check was done the slow way. The specification of CN215587201U states the problem plainly: in the existing technology, batteries were tested one by one in batches by hand after production and only then sorted, so sorting efficiency was low. A line that has to stop for manual testing cannot feed the next process step. The patent replaces the manual step with an inline station. Batteries travel on a conveyor in detection bases, a pressure sensor in each base judges the cell while it moves, and an electric cylinder with a rubber pusher diverts any out-of-spec cell into a sorting box without stopping the line. Patent Information Publication number CN215587201U Application number CN202122171465.1U Title (original) 一种电池生产用的分选机 (Inline Battery Sorting Machine with Pressure Sensing) Inventors Huang Zhengyao (Dany Huang); Chen Lucai (Tobey Chen) Current assignee XIAMEN TOB NEW ENERGY TECHNOLOGY Co., Ltd. - the registered entity of TOB NEW ENERGY Filing date 9 September 2021 Grant date 21 January 2022 Document type Utility model (kind code U) Legal status Active Anticipated expiration 9 September 2031 Drawings 7 figures Official record CN215587201U on Google Patents Ownership. TOB NEW ENERGY holds this granted utility model. It was filed under the company's registered Chinese entity (rendered in the page source and structured data) and is co-invented by Dany Huang (Zhengyao Huang) and Tobey Chen. About titles and terminology on this page. The English title above is a human-reviewed translation by TOB NEW ENERGY's engineering team, standardised to the terminology used across our equipment line; it is not a machine rendering. The original Chinese title and claims are the authoritative text - a reader comparing this page with Google Patents may notice wording differences precisely because the public record there is machine-translated. Figures and mechanism descriptions on this page are drawn from the Chinese specification and claims, not from any translation of them. A note on patent type. This is a Chinese utility model patent, which protects the mechanical structure of a device rather than a chemical formulation or process. Utility models carry a ten-year term and are examined for novelty and practical applicability. What follows is therefore a structural description - the claims define an apparatus, and the specification does not publish measured performance figures or the quality thresholds used by the pressure sensor. Any ...view more
-
Patent CN215549102U - Batch Battery Edge-Trimming Device Oct 19, 2026GRANTED UTILITY MODEL · CN215549102U · ACTIVE Patent CN215549102U - Batch Battery Edge-Trimming Device Formed batteries are stacked in a pillar magazine, pushed one cell at a time to a cushioned clamp, and edge-trimmed automatically - a batch answer to the single-cell trimmers that slowed battery lines. Full specification and drawings: CN215549102U on Google Patents Reviewed by Dany Huang, Ph.D., Founder & CEO, TOB NEW ENERGY | Last updated: 19 October 2026 Polymer lithium-ion batteries are sealed and degassed after formation, and the sealed pouch then needs its edges trimmed. The specification of CN215549102U states the bottleneck plainly: the trimming devices then in use clamped and trimmed one battery at a time, which kept throughput low on the post-formation line. CN215549102U, filed on 26 August 2021 and granted on 18 January 2022, replaces the one-by-one handling model with a batch magazine. Batteries are stacked between four pillars, a pusher feeds the bottom cell into the working zone, a cushioned clamp holds it, and a motor-driven blade trims the edge - then the next cell is fed. One operator loads the stack; the trimming cycle repeats itself. Patent Information Publication number CN215549102U Title (original) 一种电池用切片装置 (Batch Battery Edge-Trimming Device) Inventors Huang Zhengyao (Dany Huang); Chen Lucai (Tobey Chen) Current assignee XIAMEN TOB NEW ENERGY TECHNOLOGY Co., Ltd. - the registered entity of TOB NEW ENERGY Filing date 26 August 2021 Grant date 18 January 2022 Document type Utility model (kind code U) Legal status Active Anticipated expiration 26 August 2031 Drawings 4 figures Official record Google Patents - CN215549102U About titles and terminology on this page. The English title above is a human-reviewed translation by TOB NEW ENERGY's engineering team, standardised to the terminology used across our equipment line; it is not a machine rendering. The original Chinese title and claims are the authoritative text - a reader comparing this page with Google Patents may notice wording differences precisely because the public record there is machine-translated. Figures and mechanism descriptions on this page are drawn from the Chinese specification and claims, not from any translation of them. A note on patent type. This is a Chinese utility model patent, which protects the mechanical structure of a device rather than a chemical formulation or process. Utility models carry a ten-year term and are examined for novelty and practical applicability. What follows is therefore a structural description - the claims define an apparatus, and the specification does not publish measured performance figures. Any throughput or tolerance numbers for TOB's production machines come from our equipment datasheets, not from this patent document. Who holds this patent. CN215549102U is a granted Chinese utility model held by TOB NEW ENERGY and filed under our registered entity, XIAMEN TOB NEW ENERGY TECHNOLOGY Co., Ltd. Both inventors named on the pub...view more
