Battery Cutting Machine
加载中...

Battery Electrode and Aluminum Laminated Film Cutting Machine

1 Thisbattery cutting machineis used for lithium battery anode/cathode electrode and aluminum laminated film Automatic continuous roller cutting.

2 For thisautomatic cutting machine,the cutting length can be set, and it’s cutting quantity can be counted and set automatically, it is a very useful machine for battery production line.

3 This battery cutting machine is used after electrode coating for cutting the electrode to big pieces for rolling press simply.

  • Brand:

    TOB NEW ENERGY
  • item no.:

    TOB-MY-C
  • order(moq):

    1
  • Payment:

    L/C,T/T,Western Union
  • product origin:

    China
  • shipping port:

    XIAMEN
  • Lead Time:

    30days
Product Detail
500mm Width Automatic Battery Cutting Machine For Lithium Battery Electrode And Aluminum Laminated Film Roller Cuttiing


Specifications



1 Thisbattery cutting machineis used for lithium battery anode/cathode electrode and aluminum laminated film Automatic continuous roller cutting.

2 For thisautomatic cutting machine, the cutting length can be set, and it’s cutting quantity can be counted and set automatically, it is a very useful machine for battery production line.

3 This battery cutting machine is used after electrode coating for cutting the electrode to big pieces for rolling press simply.

Model

TOB-MY-C-30

TOB-MY-C-50

Source voltage

AC220V/110V  50/60HZ

Power

200W

Warranty

One year limited warranty with lifetime support

Applicable width

300mm

500mm

Cutting length

400mm adjustable

500mm adjustable

Applicable roller diameter

400mm

400mm

Cutting speed

500 times/H

400 times/H

Air supply

0.6-0.8MPa

Dimension(L*W*H)

700*650*1850mm

1000*2850*1200mm

Weight

650kg

720kg


Product Display




battery electrode cutter
