Cylindrical Battery Spot Welding Machine

This TOB-PS250 Spot welding machine mainly used for 18650 battery pack tab welding, it can weld Nickel tab thickness from 0.05-0.25mm. You can also choose our other model according to your tab Thickness.
  • Brand:

    TOB NEW ENERGY
  • item no.:

    TOB-PS250
  • order(moq):

    1
  • Payment:

    L/C,T/T,Western Union, Paypal
  • product origin:

    China
  • shipping port:

    XIAMEN
  • Lead Time:

    7
Product Detail

0.05-0.25mm thickness Pneumatic Welding Machine for 18650 Cylinder Cell Welder


SPECIFICATIONS



Dual pulse welding:

This TOB-PS250 Spot welding machine mainly used for 18650 battery pack tab welding, it can weld Nickel tab thickness from 0.05-0.25mm. You can also choose our other model according to your tab Thickness.

Dual pulse welding, the first pulse is used to the workpiece surface coating and oxide removal, and make the contact place in welding electrode produce slight deformation, improve the effective contact area, the second pulse is used to ontology metal welding, can effectively promote the quality of welding and reducing welding spatter.


Model

 TOB-PS250

Power

15KVA

secondary side of welding current

3000A

Secondary no-load voltage

5.5V

Input voltage

220V

Input frequency

50Hz

Working pressure

0.5-0.8Mpa

Welding pulse

Single pulse, double pulse, multiple pulse programmable

Welding control model

Foot switch control

Weight

30KG

Sizes(L*W*H)

400*220*360mm


PRODUCT DISPLAY



Cylinder Cell WelderCylinder Cell Welding machine


PACKAGE



Cylinder battery Welder
