LCD Digital Magnetic Hotplate Stirrer

This TOB-MS7-H550-Pro adopts LCD display actual temperature & speed, built-in PID controller ensures safe heating of the medium with overheating protection.

Brand:
TOB
item no.:
TOB-MS7-H550-Pro
order(moq):
1set
Payment:
L/C, T/T
product origin:
China
shipping port:
XIAMEN

inquiry now

Product Detail

LCD Digital Magnetic Hotplate Stirrer

SPECIFICATIONS

• LCD displays actual temperature & speed

• Built-in PID controller ensures safe heating of the medium with overheating protection

• Maximum heating plate temperature up to 550℃

• Glass ceramic work plate is resistant to corrosion and is easy to clean

• External temperature control is possible by connecting temperature sensor(PT1000) with an accuracy of ±0. 2℃

• Digital speed control with maximum range of 1500rpm

• Outstanding brushless DC motor offers more stirring power

• Two knobs enable easy adjustment of speed and temperature

• “HOT” warning flashes when work plate temperature is above 50℃ even when hotplate is turned off

• Remote function provides PC control and data transmission

Specifications	TOB-MS7-H550-Pro
Work plate Dimension [W x D]	184x184mm ( 7 inch )
Work plate material	Glass ceramic
Motor type	Brushless DC motor
Stirring positions	1
Max. stirring quantity, [H2O]	20L
Max. magnetic bar[length]	80mm
Speed range	100-1500rpm，resolution±1rpm
Speed display	LCD
Temperature display	LCD
Heating temperature range	Room Temp.-550℃, increment 1℃
Temperature control accuracy	±1℃(<100℃)±1%(>100℃)
Overheating protection	580℃
Temperature display accuracy	±0.1℃
External temperature sensor	PT1000(accuracy±0.2℃)
"Hot" warning	50℃
Data connector	RS232
Protection class	IP21
Motor rating input	18W
Motor rating output	10W
Power	1050W
Heating output	1000W
Voltage, Frequency	100-120/200-240V，50/60Hz
Dimension [WDH]	215x360x112mm
Weight	5.3kg
Timer function	-
Permissible ambient temperature and humidity	5-40℃,80%RH

Product Display


TOB-MS7-H550-S	TOB-MS7-H550-Pro
