60138 Supercapacitor Pilot Line Project

Aug 03,2023

Project Name: 60138( Dia:60mm,Height:138mm),3000F Super-Capacitor Pilot Line Project


Description: Xiamen TOB New Energy Technology Co., Ltd. designs and builds a 60138 super- capacitor pilot line for our southeast Asia customers. TOB NEW ENERGY provide a full set of super-capacitor production equipment, testing equipment and materials. TOB New Energy send engineers to the customer's factory for equipment debugging until the super-capacitor production line can run normally. After the project is completed, supply good after sales service to promise the line running stable.


Date: 2022 - 2023


Location: Southeast Asia



Customer Requirements Form

 Battery Type

 Full tab battery structure, Reduce the IR and increase the cycle life

 Battery Material

 Activated Carbon, LFP, NCM, NCA, LCO

 Battery Size

 4680, 38130, 60130, 60138, 66160,80180

 Design Capacity

 1000F,2000F,3000F,6000F

 6Ah, 10Ah, 26Ah, 60Ah

 Main Process

 Winding process

 Production Capacity

 10PCS~2000Pcs/Day

 Area

 100m2, 200m2, 300m2.....10000m2( Depend on battery quantity/Day )


(1)Design the whole line solution of large cylindrical battery.

(2)Provide a complete set of manufacturing equipment and testing equipment.

(3)Meet the customer's high capacity, high energy density, and high rate discharge requirements.

Equipment list


 Name

 Application

 Quantity

 Battery Slurry Mixer

 Slurry mixing

 1set

 Battery Coating Machine

 Slurry coating process

 1set

 Electrode Calender

 Electrode rolling press

 1set

 Electrode Cutter

 Electrode film cutting

 1set

 Electrode Slitting Machine

 Electrode slitting

 1set

 Battery Winding Machine

 Battery electrode winding

 1set

 Assembly line

 Flatting Machine

 1set

 Connector Welding Machine

 1set

 Grooving Machine

 1set

 Cap+Case Welding Machine

 1set

 Filling line

 Electrolyte Filling

 1set

 Sealing line

 Sealing the cells

 1set
