Battery Resistance Test Machine
加载中...

Battery Internal Resistance Tester

TOB-R203 Battery internal resistance tester adopts four line acquisition method, can test the resistance or impedance with or without power supply.
  • Brand:

    TOB NEW ENERGY
  • item no.:

    TOB-R203
  • order(moq):

    1
  • Payment:

    L/C,T/T
  • product origin:

    China
  • shipping port:

    XIAMEN
  • Lead Time:

    7
Product Detail

Battery internal resistance tester used for lithium battery, lead-acid battery, Ni-Cd/Ni-MH battery and all kinds of batteries.

SPECIFICATIONS




1 Usually the smaller resistance for the battery or battery core, the higher quality for the battery.

So testing battery resistance is a rapid and accurate method to check battery performance.

2 TOB-R203 Battery internal resistance tester adopts four line acquisition method, can test the resistance or

impedance with or without power supply.

3 This battery internal resistance tester is widely used for battery manufacture and battery sellers to check the

battery performance.

Machine model

Battery internal resistance tester  TOB-R203

Source voltage

AC110V-240V, 50/60HZ

Power

10-30W

Testing speed

100ms

Advantages

Can connect with computer

Suitable varies kinds battery and battery core

Buzzer alarm

Voltage test V1

Voltage range : 0-4.999V

Minimum resolution : 0.001V

Accuracy : ±0.002V

Voltage test V2

Voltage range : 0-29.99V

Minimum resolution : 0.01V

Accuracy : ±0.01V

Resistance test R1

Resistance range : 0.1—200 mΩ

Minimum resolution : 0.1mΩ

Accuracy : ±0.5 mΩ

Resistance test R2

Resistance range :1—2000 mΩ

Minimum resolution : 1mΩ

Accuracy : ±2 mΩ

Suitable batteries

Lithium battery, lithium pouch cell(Lithium polymer battery),

Nickel metal hydride, nickel cadmium battery, lead-acid battery and so on.

Dimension

250*190*90mm

Weight

2kg

Warranty

One Year limited warranty with lifetime support

Reference Pictures

1 Testing clamps



2 Polymer battery inner resistance test (Pouch cell)

 Battery Resistance Test Machine

3 18650 Battery internal resistance test

 Battery Resistance Test Machine

PACKAGE AND SHIPPING

1 Standard exported package : Internal anticollision protection, external export wooden box package

2 Shipping by express, by air, by sea according to customer's requirements to suggest the most suitable shipping mode

3 Responsible for the damage during shipping process, change the damage part for free

4 Supply with suitable voltage input and power plug according to customer's country requirements.

SERVICES

1 We supply machines with battery technology support.

2 We can also supply a full set of materials for lithium battery including polymer battery, cylinder battery, mobile phone battery, EV battery.

3 We can also supply a full set of lithium battery equipment for lab research, pilot scale research and production line.

4 We can also supply a full set of battery technology for battery design, research and producing.

We cooperated with each other, and we will do TOP OF THE BEST battery
