Manual Aluminium Punching Machine
加载中...

320*200*6mm Manual Aluminium Punching Machine

TOB-SCX-300 Manual Aluminium Punching Machine is used for lithium polymer battery/ pouch cell cup forming in the production line of making pouch cell batteries.
  • Brand:

    TOB
  • item no.:

    TOB-SCX-300
  • order(moq):

    1set
  • Payment:

    L/C,T/T
  • product origin:

    China
  • shipping port:

    XIAMEN
Product Detail
320*200*6mm Manual Aluminium Punching Machine For Lithium Battery Production Line


SPECIFICATIONS


1 TOB-SCX-300 manual aluminum laminated film punching machine is used for lithium polymer battery/ pouch cell cup forming in the production line of making pouch cell batteries.

2 The machine is used to prepare polymer cases made of Aluminum Laminated Films.

3 Thispouch forming machineis mainly used for lithium battery production line, it's mold can be bespoked according to customers' requirements.


Model

 Manual Aluminium Punching Machine TOB-SCX-300

Source voltage

AC 220V/110V, 50/60HZ

Power

500W

Warranty

One year limited warranty with lifetime support

Suitable aluminum film thickness

0.1-0.2mm

Suitable aluminum film size

320*200mm(L*W), customized, with punching depth ≤6mm

Output

200-500EA/H

Output pressure

0-5T, Adjustable

Air source

0.5-0.7MPa

Mold materials

S136 Die steel

Dimension(L*W*H)

800*760*1900mm

Weight

About 1200kg


PRODUCT DISPLAY


Aluminum laminated film punching machine

Formed aluminum laminated film

Formed aluminum laminated film

Formed aluminum laminated film




PACKAGE AND SHIPPING

1 Standard exported package : Internal anticollision protection, external export wooden box package

2 Shipping by express, by air, by sea according to customer's requirements to suggest the most suitable shipping mode

3 Responsible for the damage during shipping process, change the damage part for free

4 Supply with suitable voltage input and power plug according to customer's country requirements.

5 Supply with CO, ECO, FORM A, FORM E and any other original certificate for import custom clearance and tax relief.


SERVICES

1 We supply machines with battery technology support.

2 We can also supply a full set of materials for lithium battery including polymer battery, cylinder battery, mobile phone battery, EV battery.

3 We can also supply a full set of lithium battery equipment for lab research, pilot scale research and production line.

4 We can also supply a full set of battery technology for battery design, research and producing.
