5V300A High-Current Prismatic Cell Test Fixture

TOB-MDCJ-F1-8CH-D1 prismatic cell test fixture, rated 300A / 5V, with adjustable structure for various prismatic cell sizes. M6 terminals, adapter cables, and ≥16mm² probe contact area. Ideal for battery R&D, formation and grading.

Brand:
TOB NEW ENERGY
item no.:
TOB-MDCJ-F1-8CH-D1
order(moq):
1
Payment:
L/C,T/T
product origin:
China
shipping port:
XIAMEN

inquiry now

Product Detail

5V300A High-Current Prismatic Cell Test Fixture

Overview

The TOB-MDCJ-F1-8CH-D1 battery test fixture is designed for prismatic cells, this fixture supports up to 300 A current and a 5 V voltage range. Its fully adjustable design accommodates a wide range of cell dimensions. M6 voltage and current terminals, along with included adapter cables, provide a reliable and convenient connection for battery testing.

Specifications

Model	TOB-MDCJ-F1-8CH-D1
Test current	300 A
Cell length (L)	80 –230 mm
Cell width / thickness (W)	20 –80 mm
Cell height (H)	80 –220 mm
Tab spacing	55 –150 mm
Voltage terminal size	M6
Current terminal size	M6
Adapter cables	Included
Weight	6.5 kg
Probe contact area	≥16 mm²

Features

High Current Capability – Up to 300 A continuous current for high rate charge/discharge testing.
Adjustable Design – Three way adjustment (length, width, height, and tab spacing) makes the fixture compatible with multiple prismatic cell formats.
Low Resistance Connection – M6 bolt terminals and ≥16 mm² probe contact area minimize contact resistance, ensuring accurate measurement.
Plug and Play – Includes adapter cables for direct connection to test equipment, reducing setup time.
Robust Construction – Built with high quality insulation and metal components for long term reliability in lab and production environments.

Applications

Suitable for R&D verification, formation, grading, cycle life, and rate performance testing of lithium ion and sodium ion prismatic cells. Widely used in battery manufacturing facilities, research institutions, and third party testing laboratories.

TOB-MDCJ-F1-8CH-D1 5V300A High-Current Prismatic Cell Test Fixture

You May Also Need

Prismatic Cell Testing Clamp (Full System) — A complete testing solution that includes 8 high‑current clamps and a dedicated testing rack, based on the same TOB‑MDCJ‑F1‑8CH‑D1 platform.
Battery Tester Series — A wide selection of battery testing instruments — from charge/discharge testers to high‑precision analyzers.
