VGB-3 Benchtop Stainless Steel Vacuum Glove Box

VGB-3 Benchtop Stainless Steel Vacuum Glove Box

  • Brand:

    TOB NEW ENERGY

  • item no.:

    TOB-VGB-3

  • order(moq):

    1

  • Payment:

    L/C,T/T,Western Union

  • product origin:

    China

  • shipping port:

    XIAMEN

  • Lead Time:

    7
inquiry now
Product Detail

GB-3 Benchtop Stainless Steel Vacuum Glove Box


SPECIFICATIONS

VGB-3 is a middle size heavy duty stainless steel glove box with Airlock Chamber, Gauges and vacuum Flanges, which allow glove box operate under vacuum to remove moisture and oxygen without expensive inert gas purging, It is an ideal tool for material and chemical researchers to process air sensitive materials and solutions.

Glove Box Chamber

1 Case Material: Made of 11 gauge (3mm thickness) 304 stainless steel sheet with sport frame and plastic painting, which provide heavy duty structure for vacuum

2 Dimensions: 780mm(L) x 700mm(W) x 650mm(H)

3 Max. Positive Pressure: 810 Torr (1.1 atm)

4 Note: Gloves cannot work if pressure is higher than 810 Torr

5 Max. Vacuum Level: 0.5 Torr

6 Note: Stainless Steel case may deform at higher vacuum level

Air-lock Chamber

Dimensions: 240mm(ID) x 260mm(L)

Max. Vacuum Level: 0.05 Torr

Vacuum gauge and valves

1 Two vacuum flanges are included for glove box to achieve vacuum to remove moisture and oxygen without expensive inert gas purging

2 Do not operate under vacuum status. Vacuum process is used for purging the glove box chamber before operation.

Leakage Rate in Glove Box Chamber

< 6 Torr/hour

Gloves

One pair of Latex Gloves are included for immediate use

Glove hole diameter : 139mm (2 pcs)

Shipping Dimensions

50" x 40" x 37"

Shipping Weight

240 kg (520 lbs)


PRODUCT DISPLAY

lab glove box

PACKING
