Battery and Supercapacitor Pilot Scale Line

TOB can supply a full set of battery and supercapacitor electrode preparation lab line.

TOB offers the most professional battery and supercapacitor automatic equipment for battery research and manufacturing.

TOB offers the most professional 60138, 60130, 38130, 80180, etc. automatic supercapacitor production line for battery and supercapacitor manufacturer.

This TOB-MS7-H550-S magnetic hotplate stirrer adopts LED display for precise monitoring of temperature, a wide speed range of 0 to 1500rpm and Max. Heating plate temperature 550℃.

1600°C Single Zone Laboratory Tube Furnace with Vacuum Flanges and Corundum Tube SPECIFICATIONS The TOB-KTL1600 Modeltube furnaceis ahorizontal tube furnaceadopts Silicon molybdenum as heating element. 40 segments programmable temperature controllers are installed with 6 groups of PID adjustment. It is the ideallaboratory equipmentfor universities, research institutes, industrial and mining enterprises to do High temperatureatmosphere sintering, Atmosphere reduction, CVD experimental, vacuum annealingsuch as for preparing nano materials and film. Model Tube Size Power Dimension (L*W*H) Voltage Heating Zone  Length Max Heating  Temperature TOB-KTL1600-I Φ60*1000mm 4kw 650*450*670mm AC110V/220V 260mm 1600℃ TOB-KTL1600-II Φ80*1000mm 4kw 650*450*670mm TOB-KTL1600-III Φ100*1000mm 4kw 650*500*700mm Heating element 1800 type Silicon molybdenum Temperature controller 40 program temperature control system, With over temperature, broken accidentally protection function, 6 groups of PID adjustment Control precision of + / - 1 ℃ Furnace chamber 1800 type Polycrystal alumina fiber Tube material 99 alumina tube Vacuum Flange &  Fitting Ports Stainless steel flange with Gas nozzle, valve, pressure gauge Pressure measure  system Pressure gauge (Resistance vacuum gauge can be chosen according requirements) Air intake control Flow meter (Protons flow controller can be chosen according requirements ) Vacuum system Vacuum pump can be chosen Warranty One year limited warranty with lifetime support  Email : tob.amy@tobmachine.com  Skype : amywangbest86  Whatsapp/Phone number : +86 181 2071 5609

AI-driven double-side spot welding machine for lithium-ion battery pack assembly. 12000A transistor power, 0.4s/weld, ±0.02mm accuracy, MES integration. Supports 18650/21700/26650/32700 cells. Get specs and production analysis.

1200℃ Mini tube furnace SPECIFICATIONS The tube furnace appearance is small, high quality resistance wire heating element, Using double-shell structure and 30 program temperature control instrumentation, Zero trigger, SCR control, furnace polycrystalline alumina fiber material, stainless steel flanges tube ends can be sealed, Installation on a stainless steel flange has a gas nozzle, valve and pressure gauge,  the vacuum can reach to 10-3 Pa,Balanced with the temperature field, the surface temperature is low,  lifting the temperature and rate, energy saving,Colleges and universities, research institutes,  industrial and mining enterprises to do high-temperature sintering atmosphere, reducing atmosphere,  CVD experiment, vacuum annealing with the ideal product. Model TOB-DSP-1200℃-S-I TOB-DSP-1200℃-S-II Power 1.5 KW 1.5 KW Furnace tube size(mm) Dia 25(OD) X700 /600mm Dia50(OD)X700/600mm Dimension 340X290X415 340X290X415 Power supply voltage 220V Phase number Single-phase Heating element High-resistance wire Control mode 1,30 sections of the program can only PID temperature regulation. 2,over-temperature protection, over-temperature protection  burnout or burnout furnace heating circuit automatically cut off ,  (when the furnace temperature exceeds 1200 degrees or thermocouple burns out,  the AC relay on the main circuit will automatically disconnect the main circuit off,  the panel lights off oN, OFF lights, limited protection EAF). 3, with 485 communication interface (when an optional software standard) 4, with power protection function, namely, electrical power and then to start the stove,  the program does not start from a starting temperature rise,  but began to rise from the furnace power outage. 5, the instrument with a temperature self-tuning features Temperature control mode Intelligent PID Control accuracy +/- 1 ℃ Trigger Zero trigger SCR 106 / 16E Germany Simon Kang Max temperature 1200 ℃ Rated temperature 1100 ℃ Heating rate ≤30 ℃/ Min (Available upon request modification) Heating length 205mm Recommended heating rate ≤15  ℃/ Min Vacuum degree (Optional) 1.General vacuum and drive gas out by:TW-1.5A 2.2XZ-2 Vacuum degree pumps can be able to get around 10Pa 3.TOB-DSP-VS 0.1vacuum system can pumped 0.1Pa  (and equipped with a resistive vacuum gauge display) Certification CE Surrounding surface temperature ≤45℃  Email : tob.amy@tobmachine.com  Skype : amywangbest86  Whatsapp/Phone number : +86 181 2071 5609

Lithium Ion Battery current collector Aluminum Foil.
