High Speed Centrifuge

Centrifuge (Centrifuge) is a common tool in the lab, mainly used for solid phase and liquid phase separation of colloidal solution.

Brand:
TOB NEW ENERGY
item no.:
TOB-TG16G
order(moq):
1 set
Payment:
L/C,T/T,Western Union
product origin:
China
shipping port:
XIAMEN
Lead Time:
7 days

inquiry now

Product Detail

High Speed Laboratory Centrifuge For Lab Equipment

SPECIFICATIONS

Laboratory Centrifuge

1 Centrifuge (Centrifuge) is a common tool in the lab, mainly used for solid phase and liquid phase separation of colloidal solution.

2 Centrifuge is widely used in chemical, petroleum, food, pharmaceutical, mineral processing, coal, water treatment and shipping departments.

3 TOB-TG16G Laboratory centrifuge is high speed desktop centrifuge with speed up to 16600rpm, and capacity up to 300ml.

Model	TOB-TG16G
Max speed	16600rpm
Max relative centrifugal force	19200×g
Warranty	One year limited warranty with lifetime support
Max capacity	400ml
Speed precision	±50r/min
Time setting	0-99min
Structure	1Microcomputer control, touch panel, intuitive figures, operation parameters can be automatically memory, convenient operation 2 Multilayer damping structure, small vibration, low noise, environmental protection 3 Large torque brushless motor drive, smooth operation, free maintenance
Source voltage	AC220V 50HZ, 15A
Noise	≤60dB
Dimension(HLW)	400350340mm
Net weight	About 25kg
Configuration	12*10ml Angle rotor : one set 6×50ml Angle rotor : one set

Angle rotor spec:

Model	NO.	Capacity	Max speed	Max relative centrifugal force
Angle Rotor	No.1	12×1.5ml	16600 r/min	19200×g
	No.2	18×0.5ml	16600 r/min	19200×g
	No.3	24×1.5ml/2.0ml	13000 r/min	16060×g
	No.4	48×0.5ml	13000 r/min	14740×g
	No.5	12×5ml	13000 r/min	11500×g
	No.6	12×15ml	12000 r/min	14800×g
	No.7	4×100ml	11000 r/min	14610×g
	No.8	6×30/50ml	11000 r/min	14610×g
	No.9	12×10ml	12000 r/min	14800×g
	No.10	12×20ml	10000 r/min	10290×g
Horizontal rotor	No.11	2×2×48	3000 r/min	1400×g
