Prismatic Cell Automatic Sorting Machine with High-Precision IR & Voltage Testing (10-Grade Classification)

Product Overview

The TOB-FX11 prismatic cell automatic sorting machine is a fully automated system designed for barcode scanning, internal resistance (IR) and voltage testing, and multi-grade sorting of aluminum shell lithium-ion cells. It integrates testing and classification into a single workflow, enabling consistent cell grouping based on defined electrical parameters.

This automatic sorting machine is widely used in lithium-ion battery production where inconsistent cell matching leads to pack imbalance, reduced cycle life, and safety risks. By delivering high-precision IR and voltage measurement with automated grading, it ensures stable grouping before module assembly.

Developed based on TOB NEW ENERGY’s 24 years of battery engineering experience, the system has been validated across in-house pilot lines and real production environments. It supports efficient cell screening with traceable data and stable throughput, reducing manual error and improving pack consistency.

Key Advantages

This automatic sorting machine is engineered for high-throughput, high-consistency cell grading in prismatic cell production.

• High-precision IR & voltage testing – ensures accurate cell classification, improves pack consistency, validated using HK3560 and optional HIOKI testers in real battery testing environments
• 10-grade automatic sorting system – enables flexible classification strategies for different battery chemistries and quality standards
• ≥550 cells/hour throughput – supports pilot-scale and small-batch production with stable efficiency and reduced labor dependency
• Integrated barcode traceability – enables full data tracking (barcode, IR, voltage, time), supporting MES integration and quality control systems
• PLC + IPC control architecture – separates motion control and data processing, ensuring stable operation and reliable data acquisition

Submit Your Cell Specifications and Sorting Criteria — Get a Matched Sorting Configuration

Technical Specifications

Specification Interpretation & Application

The ±0.00001V voltage accuracy and ±0.01 mΩ internal resistance resolution are critical for precise cell grouping, especially in high-energy-density lithium-ion systems where small deviations can significantly affect pack balance and thermal behavior. The 10-channel sorting structure allows flexible grading strategies for different cell matching requirements in module and pack assembly.

With ≥550 cells/hour throughput, this system supports pilot-scale production and incoming quality control. The integration of barcode scanning and data logging enables traceability, which is essential for process validation and quality audits.

This automatic sorting machine is typically positioned after formation and aging processes, and integrates with upstream systems such as Battery Formation and Aging System and downstream assembly processes within a complete Battery Production Line.

Applications

• Battery Manufacturing Plants

Problem: Manual sorting leads to inconsistent grouping and high labor cost

Solution: Automated IR and voltage classification ensures consistent cell matching for module assembly

• Battery Pack Integrators

Problem: Cell mismatch causes imbalance and reduced cycle life

Solution: Multi-grade sorting ensures uniform electrical characteristics within packs

• Pilot Production Lines

Problem: Scaling from lab to production introduces variability

Solution: Stable throughput and data traceability support process validation

• Incoming Quality Control (IQC)

Problem: Incoming cells vary in quality and require screening

Solution: High-precision testing and classification improve supplier quality control

TOB NEW ENERGY provides full integration from testing to pack assembly, ensuring smooth transition from lab validation to pilot and mass production.

Not Sure How Many Sorting Grades You Need for Your Cells? Send Your Cell Data and Get Direct Input from a Battery Process Engineer

Quality & Support

This automatic sorting machine is manufactured under ISO 9001 and IATF 16949 quality systems, with full CE and UL compliance. All systems are tested within TOB NEW ENERGY’s in-house R&D and pilot facilities to ensure alignment with real battery production requirements.

The equipment includes a one-year standard warranty with optional extended service plans. With service experience across 6,000+ global customers, TOB provides technical support, spare parts supply, and remote or on-site assistance.

A PhD-led engineering team supports process design, sorting parameter configuration, and system integration, helping reduce risks during scale-up and production introduction.

Frequently Asked Questions

Q1: What types of batteries can this automatic sorting machine handle?

This system is designed for prismatic lithium-ion battery cells, particularly aluminum shell cells. Based on our engineering experience, it can be adapted for different chemistries with proper parameter configuration.

The standard configuration provides ±0.00001V voltage accuracy and ±0.01 mΩ internal resistance accuracy. Optional HIOKI testers are available for higher-end testing requirements.

Q3: Can the system be integrated with MES or production lines?

Yes. The system supports local data storage and optional MES integration. It can be connected with upstream Battery Formation and Aging System and downstream assembly lines for full production traceability.

Trusted by Global Innovators

TOB NEW ENERGY’s battery sorting and testing systems are deployed across battery manufacturers, research institutes, and energy storage companies worldwide. Our equipment supports lithium-ion, sodium-ion, and next-generation battery development with stable and repeatable testing performance.

With over USD 20 million invested in R&D and a 3,000+ m² testing center, all systems are validated under real production conditions. Our equipment is widely used for cell screening, grading, and pack consistency optimization.

Need consistent and traceable cell sorting for your production line? Submit your requirements to receive a tailored configuration and process recommendation.
