Roll to Roll Continuous Slitting Machine for Battery Electrode Cutting

Roll to Roll Continuous Slitting Machine for Lithium Ion Battery Electrode Cutting

SPECIFICATIONS

Using two or more continuous slitting processes for rolled material. The equipment is equipped with a precision knife holder, which can achieve high precision foil slitting. It is widely used in lithium battery, metal foil, optical film and other functional film industries.

The main features

*Correction system for feeding is set to ensure the neat coils.

*Ultrafine alloy blade, good cutting quality and long service life;

*High slitting width precision, no burrs, waves, or indentations in the finished product;

*The amount for the feed knife is adjustable, and the ratio of the knife speed to the linear speed of the material is adjustable;

*By adjusting the inlet and outlet angles, it can adapt to the cutting of different materials and thickness values;

*Single stand structure, independent knife holder, equipped with dust removal device;

*Upper and lower circular knife structure, slitting width can be adjusted by changing the sleeve;

*adjustable within 50N of upper and lower shafts;

*PLC control, HMI operation, easy to operate;

Technical Parameters

PRODUCT DISPLAY
