Vacuum Sintering Furnace

High Temperature Vacuum Furnace For Materials Hot Pressing Sintering Process Under Vacuum Condition SPECIFICATIONS This Vacuum Furnace is cycle operation type, widely used in functional ceramics, optical material, composite material, hard alloy, powder metallurgy material Hot Pressing Sintering Process under high temperature condition, it can also be used in hot forming sinter with charging protection situation. Model Vacuum Hot Pressing Furnace   TOB-VHPF-LAB Limited cold vacuum degree 5×10﹣3Pa Heating temperature 2000℃, with control precision±1℃ Temperature control mode Tungsten lai thermocouple + infrared instrument Power 25KW Working voltage 0-30V Pressure 10T Pressure head diameter 85mm Head displacement accuracy 0.02mm Pressure head stroke 100mm Tube dimension Ф80×120mm Rate of pressure rise ≤2Pa/h Inflation pressure <0.05Mpa (N2 or Ar) Warranty One year limited warranty with lifetime support  Email : tob.amy@tobmachine.com  Skype : amywangbest86  Whatsapp/Phone number : +86 181 2071 5609

1200 ℃ slider-type dual-zone PECVD system

This TOB-YCGTGX-10 solid-state batteries optical characterization test device is suitable for cross-sectional analysis via optical microscopy, Raman spectroscopy, and infrared (IR) spectroscopy.

The device is a collection of contemporary scientific research and technology needs of high-tech products. Laboratory equipment can be placed inside the product, while single purification to businesses, universities cost savings, by the customer favorite.

This digital adjustable electrolyte injector tool filling machine is using for lithium ion battery electrolyte injection.

TOB-XFZH01 1L vacuum planetary mixer for high viscosity battery slurry mixing. Integrated dispersion, vacuum system, and temperature control for lab and pilot applications.

Width:200~560mm The slitting machine is assisted by the correcting system, tension transmission system, vacuum system, etc. auxiliary precision running, to ensure the smooth running and the stability slitting of the electrodes.

Rotary pressure sealing machine SPECIFICATIONS Functional overview The machine is suitable for cylindrical battery, supercapacitor seal. The machine uses a touch screen, PLC communication control,through the implementation of pneumatic components feeding, the more bits, the seal, the material discharing etc.  Available sizes according to customer. Technical parameters For case diameter φ20 to 120mm(customer specified) For case height 50 ~ 250mm (customer specified) Production capacity  about 10 pcs/ min Gas source  0.4 ~ 0.7MPa Operating voltage Three-phase 380V / 50HZ Total power 2KW Dimensions (L * W * H) 1300 * 550 * 1350mm  Email : tob.amy@tobmachine.com  Skype : amywangbest86  Whatsapp/Phone number : +86 181 2071 5609
