China Leading Standing Vacuum Box Manufacturer
Loading...
Standing Vacuum Box Standing Vacuum Box

Standing Vacuum Box

Standing vacuum box

  • item no.:

    TOB-YXY-SVB

  • order(moq):

    1set

  • Payment:

    L/C,T/T,Western Union, Paypal

  • product origin:

    China

  • shipping port:

    XIAMEN

  • Lead Time:

    7days
inquiry now
Product Detail

Standing vacuum box


SPECIFICATIONS


Overview of functions

1. This device is mainly used for batteries rapid and uniform absorb the electrolyte under vacuum state;

2. Cylinder drive the chamber up and down, convenient discharge, vacuum sealing;

3. With the watching window, batteries cases can be observed;

4. Can be used in the glove box or configured to work on the assembly line;

5.PLC automatic control, standing time and frequency can be set arbitrarily;

6. Equipped with safety grating protection;

7. Adapt to different battery specifications, and easy to adjust.


The basic parameters

The cavity size (L * W * H)

860 * 542 * 712mm

Dimensions (L * W * H)

900 * 620 * 800mm

Configure Power

AC220 / 50HZ, 0.2KW

Weight

100kg

The vacuum source

-0.098MPa, 40L / s

Vacuum degree

-97 ~ -90kpa


PRODUCT DISPLAY

Standing vacuum box



 Email : tob.amy@tobmachine.com

 Skype : amywangbest86

 Whatsapp/Phone number : +86 181 2071 5609

Related Tags :

Vacuum Box

injection pump

ceramic pump

Standing Box For Battery

Small Standing Vacuum Box
