Automatic Battery Production Line

The automatic film covering machine is used for cylindrical battery automatic sleeve PET/PVC sleeve, add insulation pad and heat shrink molding.

1200℃ Mini tube furnace SPECIFICATIONS The tube furnace appearance is small, high quality resistance wire heating element, Using double-shell structure and 30 program temperature control instrumentation, Zero trigger, SCR control, furnace polycrystalline alumina fiber material, stainless steel flanges tube ends can be sealed, Installation on a stainless steel flange has a gas nozzle, valve and pressure gauge,  the vacuum can reach to 10-3 Pa,Balanced with the temperature field, the surface temperature is low,  lifting the temperature and rate, energy saving,Colleges and universities, research institutes,  industrial and mining enterprises to do high-temperature sintering atmosphere, reducing atmosphere,  CVD experiment, vacuum annealing with the ideal product. Model TOB-DSP-1200℃-S-I TOB-DSP-1200℃-S-II Power 1.5 KW 1.5 KW Furnace tube size(mm) Dia 25(OD) X700 /600mm Dia50(OD)X700/600mm Dimension 340X290X415 340X290X415 Power supply voltage 220V Phase number Single-phase Heating element High-resistance wire Control mode 1,30 sections of the program can only PID temperature regulation. 2,over-temperature protection, over-temperature protection  burnout or burnout furnace heating circuit automatically cut off ,  (when the furnace temperature exceeds 1200 degrees or thermocouple burns out,  the AC relay on the main circuit will automatically disconnect the main circuit off,  the panel lights off oN, OFF lights, limited protection EAF). 3, with 485 communication interface (when an optional software standard) 4, with power protection function, namely, electrical power and then to start the stove,  the program does not start from a starting temperature rise,  but began to rise from the furnace power outage. 5, the instrument with a temperature self-tuning features Temperature control mode Intelligent PID Control accuracy +/- 1 ℃ Trigger Zero trigger SCR 106 / 16E Germany Simon Kang Max temperature 1200 ℃ Rated temperature 1100 ℃ Heating rate ≤30 ℃/ Min (Available upon request modification) Heating length 205mm Recommended heating rate ≤15  ℃/ Min Vacuum degree (Optional) 1.General vacuum and drive gas out by:TW-1.5A 2.2XZ-2 Vacuum degree pumps can be able to get around 10Pa 3.TOB-DSP-VS 0.1vacuum system can pumped 0.1Pa  (and equipped with a resistive vacuum gauge display) Certification CE Surrounding surface temperature ≤45℃  Email : tob.amy@tobmachine.com  Skype : amywangbest86  Whatsapp/Phone number : +86 181 2071 5609

Quick assembly split coin cell for R&D  battery material testing.

This machine is suitable for sealing process of sodium ion pouch battery. With temperature alarm function to prevent misuse；The device has a battery tab positioning block, which can position the battery tab more accurately.

TOB-ZCB-01 This piston pump is designed for the battery slurry slot die coating machine. It feeds the battery slurry to the slot die applicator.

TOB-JRJ-02 Manual Winding Machine is used for winding battery anode/cathode electrodes with separator together in the research of Li-ion battery cells.

This TOB-HJ-N210 Prismatic Cell Helium Mass Spectrometer Leak Detector is suitable for the leakage detection of prismatic cell. Manual pick and place material, automatic leakage detection and give the test results, OK no alarm, NG alarm.

Horizontal power battery needling testing machine SPECIFICATIONS 1.Technical requirements Model Horizontal Power battery needling testing machine TOB-BE-AP-9002D Pressure range 1000N~20000N Customized Dimension W2400*D1000*H1200MM Weight 500kg Testing space W1000*D500*H500MM Customized Power 2500W Needling mode Oil pressure Needling force ±1% accuracy Needling speed 10-40MM/S, adjustable, Needling speed error ±0.1MM/S Unit Conversion Kg/N/Lb 2.Standard configuration Needling host A set Protective case A set Needling holder A set Big battery fixing clip A set White steel needle/ Tungsten steel needle A set Surveillance camera system（Optional） A set Voltage acquisition system（Optional） A set PACKAGE AND SHIPPING 1 Standard exported package : Internal anticollision protection, external export wooden box package 2 Shipping by express, by air, by sea according to customer's requirements to suggest the most suitable shipping mode 3 Responsible for the damage during shipping process, change the damage part for free 4 Supply with suitable voltage input and power plug according to customer's country requirements. SERVICES 1 We supply machines with battery technology support. 2 We can also supply a full set of materials for lithium battery including polymer battery, cylinder battery, mobile phone battery, EV battery. 3 We can also supply a full set of lithium battery equipment for lab research, pilot scale research and production line. 4 We can also supply a full set of battery technology for battery design, research and producing. We cooperated with each other, and we will do TOP OF THE BEST battery  Email : tob.amy@tobmachine.com  Skype : amywangbest86  Whatsapp/Phone number : +86 181 2071 5609
